The NU 1876 ECMP is a single row cylindrical roller bearing with a 380mm bore and 480mm outer diameter, crafted from sturdy chrome steel for durability. It handles combined loads up to 126225 lbf and operates smoothly at speeds up to 2000 RPM.
Its open design allows for easy lubrication with grease or oil, while the PA66 cage ensures reliable performance. The bearing works well in temperatures ranging from -30°C to 110°C.
This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial machinery or large gearboxes where robust performance is needed.
Weighing 20kg, it’s built to handle substantial loads while maintaining stability. Compliant with RoHS and REACH standards for safe and eco-friendly use.
"*" indicates required fields
Performance Features of NU 1876 ECMP Bearing
NU 1876 ECMP Bearing is built with chrome steel rings and rollers, offering robust resistance to combined loads.
Its dynamic radial load capacity reaches 126225 lbf, ensuring reliable performance in heavy-duty applications.
The PA66 cage keeps the rollers centred, reducing friction and extending operational life.
With a maximum speed of 2000 rpm, it delivers both durability and efficiency.
NU 1876 ECMP Bearing operates smoothly in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, minimising maintenance needs.
Industrial Uses of NU 1876 ECMP Bearing
NU 1876 ECMP Bearing is commonly used in heavy machinery like industrial gearboxes and large conveyor systems, where its high radial load capacity ensures reliable performance. The open design allows for easy lubrication, making it suitable for continuous operation in demanding environments.
In wind turbine applications, NU 1876 ECMP Bearing handles combined loads efficiently, thanks to its robust chrome steel construction. Its large bore size and metric dimensions make it a preferred choice for European-designed renewable energy systems.
For mining equipment, NU 1876 ECMP Bearing’s durability and high dynamic load rating make it ideal for crushers and vibrating screens. The PA66 cage material provides additional resistance to wear in harsh operating conditions.
What Makes NU 1876 ECMP Bearing a Preferred Choice?
NU 1876 ECMP Bearing is often selected for paper mill machinery due to its ability to withstand high speeds and heavy loads. The roller-centred design ensures smooth rotation, reducing maintenance downtime in production lines.
In steel processing plants, NU 1876 ECMP Bearing’s temperature resistance makes it suitable for hot rolling mills. Its grease or oil lubrication options provide flexibility for different operating conditions.
