The NJ 2216 ECM is a single-row cylindrical roller bearing with an 80mm bore and 140mm outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 47700 lbf and operates smoothly at speeds up to 6000 RPM.
Its brass cage keeps rollers centred for even load distribution, while the open design allows easy lubrication with grease or oil. The bearing performs reliably in temperatures from -30°C to 110°C.
With a width of 33mm and a weight of 2.27kg, it’s compact yet robust for industrial use. The inner ring design ensures stable axial displacement up to 1.4mm.
Ideal for heavy-duty machinery like gearboxes or pumps, where radial and axial loads are present. Compliant with RoHS and REACH standards, it’s a dependable choice for replacements, interchangeable with SKF models.
"*" indicates required fields
Performance Features of NJ 2216 ECM Bearing
NJ 2216 ECM Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 47,700 lbf, ensuring reliable performance in demanding conditions.
The brass cage keeps the rollers centred, reducing friction and extending service life.
With a maximum speed of 6,000 rpm, it balances durability and efficiency for various applications.
NJ 2216 ECM Bearing operates smoothly in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, reducing maintenance needs.
The precise chamfer dimensions of 2 mm ensure easy installation and alignment.
This bearing is ideal for heavy-duty machinery requiring high load capacity and long-lasting performance.
Industrial Uses of NJ 2216 ECM Bearing
NJ 2216 ECM Bearing is commonly used in heavy machinery like gearboxes and industrial pumps, where its cylindrical roller design handles both radial and axial loads efficiently. The brass cage ensures smooth operation even at high speeds up to 6000 rpm.
Where Is NJ 2216 ECM Bearing Used?
In automotive applications, NJ 2216 ECM Bearing supports transmissions and differential systems, thanks to its robust chrome steel construction. Its metric sizing makes it a reliable choice for European and Asian vehicle manufacturers.
Built for Heavy-Duty Use: NJ 2216 ECM Bearing
This bearing excels in conveyor systems and material handling equipment, where its high dynamic radial load capacity of 47700 lbf ensures long-lasting performance. The open design allows for easy lubrication and maintenance.
Automotive vs Aerospace: Applications of NJ 2216 ECM Bearing
While NJ 2216 ECM Bearing is popular in automotive drivetrains, it also finds use in aerospace auxiliary systems due to its precision and temperature resilience. The combined load capability makes it versatile for various demanding environments.
Perfect Fit for Automation: NJ 2216 ECM Bearing
In robotic arms and automated assembly lines, NJ 2216 ECM Bearing provides reliable motion control with minimal friction. Its brass cage and chrome steel rollers ensure durability in continuous operation.
