Single Row Cylindrical Roller Bearings With Inner Ring NJ 1076 MA
Single Row Cylindrical Roller Bearings With Inner Ring NJ 1076 MA

Single Row Cylindrical Roller Bearings With Inner Ring NJ 1076 MA

The NJ 1076 MA is a single-row cylindrical roller bearing with a 380mm bore and 560mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 256500 lbf and runs smoothly at speeds up to 2000 RPM.

Its brass cage and open design make it easy to maintain, while the inner ring provides stability under heavy loads. The bearing operates well in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Ideal for heavy machinery or industrial equipment where high radial and axial loads are present.

Weighing 71kg, it’s a robust choice for demanding applications. Compliant with RoHS and REACH standards for safe use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number NJ 1076 MA
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 380 mm
  • Bore Dia Tolerance -0.04mm to 0
  • Outer Dia 560 mm
  • Outer Dia Tolerance -0.05mm to 0
  • Width 82 mm
  • Width Tolerance -0.40mm to 0
  • Shoulder Dia Of Inner Ring 443 mm
  • Chamfer Dimension r1,2(min.) 5 mm
  • Permissible Axial Displacement(max.) 10.8 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass cage, outer ring centred
  • Dynamic Radial Load 256500 lbf
  • Static Radial Load 434250 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 2000 rpm
  • Weight 71 kg
  • Shoulder Dia Of Outer Ring 495 mm
  • Raceway Diameter Of Inner Ring 425 mm

Features

How Does NJ 1076 MA Bearing Handle Combined Loads?

NJ 1076 MA Bearing is built with chrome steel rings and rollers, offering strong resistance to both radial and axial loads.
Its dynamic radial load capacity reaches 256500 lbf, ensuring reliable performance in heavy-duty applications.
The brass cage keeps the rollers aligned, reducing friction and extending the bearing’s service life.
With a maximum speed of 2000 rpm, it balances durability and efficiency in demanding conditions.

Application

Industrial Uses of NJ 1076 MA Bearing
NJ 1076 MA Bearing is commonly used in heavy machinery like industrial gearboxes and large conveyor systems, where its high radial load capacity is essential. The brass cage design helps reduce friction, making it suitable for continuous operation.

Where Is NJ 1076 MA Bearing Used?
You’ll often find NJ 1076 MA Bearing in wind turbines and mining equipment, thanks to its ability to handle combined loads. Its chrome steel construction ensures long-lasting performance even in harsh environments.

Built for Heavy-Duty Use: NJ 1076 MA Bearing
NJ 1076 MA Bearing excels in applications like steel mills and paper processing machines, where durability is key. The open seal design allows for easy lubrication, extending its service life.

Automotive vs Aerospace: Applications of NJ 1076 MA Bearing
In automotive settings, NJ 1076 MA Bearing supports large drivetrain components, while in aerospace, it’s used in landing gear systems. Its metric sizing ensures compatibility across various industries.

Perfect Fit for Automation: NJ 1076 MA Bearing
NJ 1076 MA Bearing is ideal for robotic arms and automated assembly lines, where precision and reliability are crucial. The high-speed capability makes it a versatile choice for modern manufacturing.
