The N 216 ECP is a single row cylindrical roller bearing with an 80mm bore and 140mm outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 36000 lbf and operates smoothly at speeds up to 6000 RPM.
Its open design allows easy lubrication with grease or oil, while the PA66 cage ensures durability and centred roller alignment. The bearing performs reliably in temperatures ranging from -30°C to 110°C.
This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for industrial machinery or gear systems where combined radial and axial loads are present.
Weighing 1.53kg, it offers a robust solution for demanding applications. Compliant with RoHS and REACH standards for safe and eco-friendly use.
"*" indicates required fields
Performance Features of N 216 ECP Bearing
N 216 ECP Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 36000 lbf, ensuring reliable performance in heavy-duty applications.
The PA66 cage keeps the rollers centred, reducing friction and extending service life.
With a maximum speed of 6000 rpm, it balances durability and efficiency.
How Is N 216 ECP Bearing Engineered for Reliability?
N 216 ECP Bearing features a single-row cylindrical design, optimised for combined load applications.
The chrome steel construction ensures durability, even under high radial loads.
Its open design allows for easy lubrication with grease or oil, reducing maintenance needs.
The bearing operates smoothly within a temperature range of -30° to 110°C.
Built for Durability: N 216 ECP Bearing
N 216 ECP Bearing’s chrome steel rollers and rings provide excellent wear resistance.
The PA66 cage minimises friction, ensuring smooth operation at speeds up to 6000 rpm.
Its static radial load capacity of 37350 lbf makes it suitable for demanding environments.
The bearing’s design allows for permissible axial displacement of up to 1.4 mm.
Steel vs Ceramic Bearings: Strengths of N 216 ECP Bearing
N 216 ECP Bearing uses chrome steel for both rings and rollers, offering high strength and durability.
Its dynamic radial load capacity of 36000 lbf ensures reliable performance in heavy-load scenarios.
The PA66 cage reduces friction and noise, making it ideal for precision applications.
With a wide temperature range, it performs well in various industrial conditions.
Industrial Uses of N 216 ECP Bearing
N 216 ECP Bearing is commonly used in heavy machinery like industrial gearboxes and electric motors, where its cylindrical roller design handles combined loads efficiently. The chrome steel construction ensures durability even in demanding environments.
Where Is N 216 ECP Bearing Used?
You’ll often find N 216 ECP Bearing in automotive transmissions, where its high-speed capability and radial load support keep things running smoothly. The open design allows for easy lubrication, extending its service life.
Perfect Fit for Automation: N 216 ECP Bearing
N 216 ECP Bearing works well in robotic arms and conveyor systems, thanks to its precise axial displacement tolerance. The PA66 cage reduces friction, making it ideal for continuous operation.
Medical vs Industrial: Where N 216 ECP Bearing Excels
In medical devices like MRI scanners, N 216 ECP Bearing provides reliable performance with minimal maintenance. Its grease or oil lubrication options make it versatile for different industrial applications too.
