Single Row Angular Contact Ball Bearings (General) 7413 BCBM
Single Row Angular Contact Ball Bearings (General) 7413 BCBM

Single Row Angular Contact Ball Bearings (General) 7413 BCBM

The 7413 BCBM is a single-row angular contact ball bearing with a 65mm bore and 160mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 29250 lbf and operates smoothly at speeds up to 7000 RPM.

Its 40° contact angle efficiently handles combined loads, while the brass cage enhances durability. The open design simplifies lubrication, and it performs reliably in temperatures from -30°C to 110°C.

This bearing is interchangeable with SKF models, offering a practical replacement option. Suited for machinery like pumps or gearboxes where angular contact is needed.

Weighing 4kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 7413 BCBM
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 160 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 37 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 101.38 mm
  • External Diameter On Inner Ring (Small Side Face) 83.75 mm
  • Internal Diameter On Outer Ring 125 mm
  • Chamfer Dimension 2.1 mm
  • Distance Pressure Point (a) 65 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 29250 lbf
  • Static Radial Load 21712 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 7000 rpm
  • Weight 4 kg
  • Price($) 127.49

Features

Performance Features of 7413 BCBM Bearing

7413 BCBM Bearing features a 40° contact angle, optimised for handling combined radial and axial loads.
Its chrome steel construction ensures durability and resistance to wear in demanding applications.

The brass cage maintains ball alignment, reducing friction and enhancing smooth operation.
With a dynamic radial load capacity of 29,250 lbf, it performs reliably under heavy loads.

7413 BCBM Bearing operates efficiently at speeds up to 7,000 rpm, balancing performance and longevity.
Its P6 tolerance class (ABEC-3) ensures consistent precision in various industrial applications.

Application

Industrial Uses of 7413 BCBM Bearing
7413 BCBM Bearing is commonly used in machine tools, where its angular contact design helps manage combined radial and axial loads. The brass cage ensures smooth operation even at higher speeds, making it suitable for precision machining.

Where Is 7413 BCBM Bearing Used?
You’ll often find 7413 BCBM Bearing in automotive applications like wheel hubs, where its 40° contact angle provides stability. Its chrome steel construction also handles the stresses of daily driving with ease.

Built for Heavy-Duty Use: 7413 BCBM Bearing
7413 BCBM Bearing works well in conveyor systems, thanks to its robust design and high dynamic load capacity. The open seal type allows for easy lubrication, extending its lifespan in demanding environments.

Automotive vs Aerospace: Applications of 7413 BCBM Bearing
In automotive settings, 7413 BCBM Bearing supports gearboxes, while in aerospace, it’s used in auxiliary systems. Its P6 tolerance ensures reliable performance in both high-precision and high-load scenarios.

Perfect Fit for Automation: 7413 BCBM Bearing
7413 BCBM Bearing is ideal for robotic arms, where its angular contact design ensures precise movement. The lubricated construction reduces friction, keeping operations smooth over long periods.
