Single Row Angular Contact Ball Bearings (General) 7411 BGM
Single Row Angular Contact Ball Bearings (General) 7411 BGM

Single Row Angular Contact Ball Bearings (General) 7411 BGM

The 7411 BGM is a single-row angular contact ball bearing with a 55mm bore and 140mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 24975 lbf and operates smoothly at speeds up to 8000 RPM.
Its 40° contact angle efficiently handles combined loads, while the brass cage enhances durability. The open design simplifies lubrication, making maintenance straightforward.
This bearing suits applications like pumps or gearboxes where angular loads are present. With a weight of 2.35kg, it’s robust yet manageable for industrial use. Compliant with RoHS and REACH standards, it’s a reliable choice for various machinery needs.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 7411 BGM
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 55 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 140 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 33 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 88.5 mm
  • External Diameter On Inner Ring (Small Side Face) 72.01 mm
  • Internal Diameter On Outer Ring 108.4 mm
  • Chamfer Dimension 2.1 mm
  • Distance Pressure Point (a) 57.8 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 24975 lbf
  • Static Radial Load 17212 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 8000 rpm
  • Weight 2.35 kg
  • Price($) 84.43

Features

Performance Features of 7411 BGM Bearing

7411 BGM Bearing is designed with a 40° contact angle, optimising load distribution for angular contact applications.
Its chrome steel rings and balls ensure durability under high dynamic radial loads of up to 24,975 lbf.

The brass cage maintains ball alignment, reducing friction and wear during operation.
With a maximum speed of 8,000 rpm, it delivers reliable performance in various conditions.

7411 BGM Bearing operates efficiently within a temperature range of -30° to 110°C.
Its P6 tolerance class (ABEC-3) ensures precision and smooth running for demanding tasks.

Application

Industrial Uses of 7411 BGM Bearing
7411 BGM Bearing is commonly used in machine tools, where its angular contact design handles combined radial and axial loads efficiently. The brass cage ensures smooth operation even at higher speeds, making it suitable for precision machining.

In automotive applications, 7411 BGM Bearing supports components like wheel hubs and transmissions, thanks to its robust chrome steel construction. The P6 tolerance class provides the accuracy needed for reliable performance in demanding conditions.

For automation systems, 7411 BGM Bearing fits well in robotic arms and conveyor belts, where its 40° contact angle optimises load distribution. The open seal type allows for easy lubrication, extending service life in continuous operation.

Medical imaging devices benefit from 7411 BGM Bearing’s stable performance, as its low vibration levels ensure quiet and precise movement. The wide temperature range also makes it adaptable to various clinical environments.

In household appliances like washing machines, 7411 BGM Bearing’s durability reduces wear and tear over time. Its metric sizing ensures compatibility with a range of European and Asian models.
