Single Row Angular Contact Ball Bearings (General) 7319 BECBP
Single Row Angular Contact Ball Bearings (General) 7319 BECBP

Single Row Angular Contact Ball Bearings (General) 7319 BECBP

The 7319 BECBP is a single-row angular contact ball bearing with a 95mm bore and 200mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 40500 lbf and operates smoothly at speeds up to 4300 RPM.

With a 40° contact angle, it efficiently manages combined radial and axial loads. The open design and nylon cage ensure durability while allowing easy lubrication.

This bearing is interchangeable with SKF models, making it a practical choice for replacements. Suitable for industrial machinery or gear systems where angular contact is needed.

Weighing 6.05kg, it’s built to last in temperatures from -30°C to 110°C. Compliant with RoHS and REACH standards for safe and reliable use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 7319 BECBP
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 95 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 200 mm
  • Outer Dia Tolerance -0.02mm to 0
  • Width 45 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 136.2 mm
  • External Diameter On Inner Ring (Small Side Face) 114.92 mm
  • Internal Diameter On Outer Ring 161.25 mm
  • Chamfer Dimension 3 mm
  • Distance Pressure Point (a) 84 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 40500 lbf
  • Static Radial Load 36675 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 4300 rpm
  • Weight 6.05 kg
  • Price($) 149.71

Features

Performance Features of 7319 BECBP Bearing

7319 BECBP Bearing features a 40° contact angle, optimised for handling combined radial and axial loads.
Its chrome steel construction ensures durability and resistance to wear in demanding applications.

The nylon cage in 7319 BECBP Bearing reduces friction and noise, enhancing operational smoothness.
With a dynamic radial load capacity of 40,500 lbf, it performs reliably under heavy loads.

7319 BECBP Bearing operates efficiently within a temperature range of -30° to 110°C.
Its P6 tolerance class (ABEC-3) ensures precision and consistent performance.

Designed for high-speed applications, 7319 BECBP Bearing supports speeds up to 4,300 rpm.
The open seal type allows for easy lubrication and maintenance.

Application

Industrial Uses of 7319 BECBP Bearing
7319 BECBP Bearing is commonly used in heavy machinery like industrial pumps and compressors, where its angular contact design efficiently handles combined radial and axial loads.
The open seal type allows for easy lubrication, ensuring long service life even in demanding environments.

Where Is 7319 BECBP Bearing Used?
In automotive applications, 7319 BECBP Bearing is often found in wheel hubs and transmissions, providing reliable performance under high-speed conditions.
Its chrome steel construction and nylon cage offer a good balance of strength and reduced friction.

Built for Heavy-Duty Use: 7319 BECBP Bearing
7319 BECBP Bearing excels in construction equipment, such as cranes and excavators, where its robust design withstands heavy loads and harsh conditions.
The P6 tolerance class ensures consistent precision, making it suitable for critical applications.

Automotive vs Aerospace: Applications of 7319 BECBP Bearing
In automotive systems, 7319 BECBP Bearing supports high-speed rotations in drivetrains, while in aerospace, it’s used in auxiliary systems requiring precise angular contact.
The temperature range of -30° to 110°C makes it versatile for various climates and operating conditions.

Perfect Fit for Automation: 7319 BECBP Bearing
7319 BECBP Bearing is ideal for robotic arms and automated assembly lines, where its angular contact design ensures smooth and precise movement.
The lubricated construction reduces maintenance needs, keeping downtime to a minimum.
