The 7318 BEGAY is a single-row angular contact ball bearing with a 90mm bore and 190mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 37350 lbf and operates smoothly at speeds up to 4500 RPM.
With a 40° contact angle, it efficiently manages combined radial and axial loads. The brass cage enhances durability, while the open design simplifies lubrication and maintenance.
This bearing suits applications like pumps or gearboxes where precise angular contact is needed. It works reliably in temperatures from -30°C to 110°C and meets P6 tolerance standards.
Weighing 5.2kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH, it’s interchangeable with SKF bearings for easy replacement.
"*" indicates required fields
Performance Features of 7318 BEGAY Bearing
7318 BEGAY Bearing features a 40° contact angle, optimised for handling combined radial and axial loads.
Its chrome steel construction ensures durability and resistance to wear in demanding applications.
The brass cage maintains ball alignment, reducing friction and enhancing smooth operation.
With a dynamic radial load capacity of 37,350 lbf, it performs reliably under heavy loads.
7318 BEGAY Bearing operates efficiently at speeds up to 4,500 rpm, balancing performance and longevity.
Its P6 tolerance class ensures precision, making it suitable for high-accuracy applications.
Designed for a temperature range of -30° to 110°C, 7318 BEGAY Bearing adapts to various environments.
The open seal type allows for easy lubrication, simplifying maintenance.
Industrial Uses of 7318 BEGAY Bearing
The 7318 BEGAY Bearing is commonly used in heavy machinery like industrial pumps and compressors, where its 40° contact angle efficiently handles combined radial and axial loads.
Its brass cage and chrome steel construction ensure durability in high-load environments, making it a reliable choice for continuous operation.
Where Is 7318 BEGAY Bearing Used?
In automotive applications, 7318 BEGAY Bearing supports wheel hubs and transmissions, providing smooth performance under angular loads.
The metric dimensions and P6 tolerance class make it compatible with precision components in European and Asian vehicles.
Built for Heavy-Duty Use: 7318 BEGAY Bearing
This bearing excels in robotics and automation, particularly in robotic arms and CNC machines, where precise movement is essential.
The open design allows for easy lubrication, extending its service life in demanding industrial settings.
Medical vs Industrial: Where 7318 BEGAY Bearing Excels
While not typically used in medical devices, 7318 BEGAY Bearing is ideal for industrial equipment like conveyor systems and gearboxes.
Its high dynamic radial load capacity ensures reliable performance in heavy-duty applications.
Practical Applications of 7318 BEGAY Bearing
In consumer electronics manufacturing, 7318 BEGAY Bearing can be found in automated assembly lines, ensuring smooth and precise operation.
The chrome steel rings and brass cage provide a balance of strength and wear resistance for long-term use.
