The 7318 BECBM is a single-row angular contact ball bearing with a 90mm bore and 190mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 37350 lbf and operates smoothly at speeds up to 5600 RPM.
With a 40° contact angle, it efficiently manages combined radial and thrust loads. The brass cage enhances durability, while the open design allows for easy lubrication.
This bearing is interchangeable with SKF models, making it a practical choice for replacements. Suitable for industrial machinery, pumps, or gearboxes where angular contact is needed.
Weighing 5.2kg, it’s robust yet manageable. Compliant with RoHS and REACH standards, it works in temperatures from -30°C to 110°C.
"*" indicates required fields
Performance Features of 7318 BECBM Bearing
7318 BECBM Bearing is built with a 40° contact angle, ideal for handling combined radial and axial loads.
Its chrome steel rings and balls provide strength, while the brass cage ensures smooth operation.
The dynamic radial load capacity of 37350 lbf makes it suitable for demanding applications.
With a maximum speed of 5,600 rpm, it balances performance and durability.
7318 BECBM Bearing operates efficiently in temperatures ranging from -30° to 110°C.
Its P6 tolerance class ensures precision, making it reliable for various industrial uses.
Industrial Uses of 7318 BECBM Bearing
The 7318 BECBM Bearing is commonly used in industrial machinery, especially where high radial and axial loads are present, such as in heavy-duty pumps and compressors. Its brass cage and chrome steel construction ensure durability in demanding environments.
What Makes 7318 BECBM Bearing a Preferred Choice?
With a 40° contact angle, 7318 BECBM Bearing excels in applications like gearboxes and machine tool spindles, providing stable performance under combined loads. The P6 tolerance class ensures precision in high-speed operations.
Built for Heavy-Duty Use: 7318 BECBM Bearing
In automotive systems, 7318 BECBM Bearing supports components like wheel hubs and transmissions, where its robust design handles both radial and thrust forces. The lubricated design also extends service life in high-temperature conditions.
Automotive vs Aerospace: Applications of 7318 BECBM Bearing
While 7318 BECBM Bearing is popular in automotive drivetrains, its precision also makes it suitable for aerospace applications like actuator systems. The metric sizing ensures compatibility with a wide range of international standards.
Perfect Fit for Automation: 7318 BECBM Bearing
In robotics and automation, 7318 BECBM Bearing is often found in robotic arms and CNC machines, where its angular contact design ensures smooth, precise movement. The open seal type allows for easy maintenance in high-use scenarios.
