The 7314 BEGAPH is a single-row angular contact ball bearing with a 70mm bore and 150mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 28575 lbf and operates smoothly at speeds up to 5600 RPM.
Its 40° contact angle efficiently handles combined loads, while the open design allows easy lubrication. The nylon cage reduces friction and noise, enhancing performance.
This bearing suits applications with angular loads, such as pumps or gearboxes. It works reliably in temperatures from -30°C to 110°C.
Weighing 2.65kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a dependable choice for industrial use. Interchangeable with SKF bearings, it simplifies replacements.
"*" indicates required fields
Performance Features of 7314 BEGAPH Bearing
7314 BEGAPH Bearing features a 40° contact angle, optimised for handling combined radial and axial loads.
Its chrome steel construction ensures durability and resistance to wear in demanding applications.
The nylon cage in 7314 BEGAPH Bearing reduces friction and noise, making it suitable for precision tasks.
With a dynamic radial load capacity of 28,575 lbf, it performs reliably under heavy loads.
7314 BEGAPH Bearing operates smoothly at speeds up to 5,600 rpm, balancing performance and efficiency.
Its P6 tolerance class ensures consistent precision, meeting ABEC-3 standards for quality.
Designed for temperatures from -30° to 110°C, 7314 BEGAPH Bearing adapts to various working conditions.
The open seal type allows for easy lubrication, extending maintenance intervals.
Industrial Uses of 7314 BEGAPH Bearing
The 7314 BEGAPH Bearing is commonly used in machine tools, where its angular contact design handles combined radial and axial loads efficiently. The open seal type allows for easy lubrication, extending service life in demanding industrial environments.
What Makes 7314 BEGAPH Bearing a Preferred Choice?
In automotive applications like wheel hubs, 7314 BEGAPH Bearing offers reliable performance due to its chrome steel construction. The 40° contact angle ensures stability even under high-speed conditions.
Built for Heavy-Duty Use: 7314 BEGAPH Bearing
This bearing excels in conveyor systems, where its nylon cage reduces friction and noise. The P6 tolerance class provides precision for smooth operation in continuous-use scenarios.
Medical vs Industrial: Where 7314 BEGAPH Bearing Excels
While suitable for industrial gearboxes, 7314 BEGAPH Bearing also fits medical centrifuges due to its balanced load capacity. The lubricated design ensures consistent performance in both fields.
Perfect Fit for Automation: 7314 BEGAPH Bearing
In robotic arms, 7314 BEGAPH Bearing’s single-row design allows for compact installation. Its dynamic radial load rating supports repetitive movements without compromising accuracy.
