The 7314 BECBY is a single-row angular contact ball bearing with a 70mm bore and 150mm outer diameter, crafted from sturdy chrome steel. Its 40° contact angle efficiently manages combined radial and axial loads, supporting up to 28575 lbf dynamically.
The brass cage enhances durability and reduces friction, allowing smooth operation at speeds up to 5600 RPM. Its open design simplifies lubrication, making maintenance straightforward.
With a P6 tolerance class, this bearing offers reliable precision for demanding applications. It performs well in temperatures from -30°C to 110°C, suitable for industrial machinery or pumps.
Weighing 2.65kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s interchangeable with SKF models for easy replacements.
"*" indicates required fields
Performance Features of 7314 BECBY Bearing
7314 BECBY Bearing is built with a 40° contact angle, optimised for handling combined radial and axial loads.
Its chrome steel rings and balls provide strength, while the brass cage ensures smooth operation.
The bearing’s dynamic radial load capacity reaches 28575 lbf, making it suitable for demanding applications.
With a maximum speed of 5,600 rpm, it balances performance and durability.
7314 BECBY Bearing operates in temperatures from -30° to 110°C, adapting to various environments.
Its P6 tolerance class ensures precision and reliability in high-performance machinery.
The open design simplifies lubrication, reducing maintenance needs.
Weighing 2.65 kg, it offers a robust yet manageable solution for industrial use.
Industrial Uses of 7314 BECBY Bearing
The 7314 BECBY Bearing is commonly used in industrial machinery like pumps and compressors, where its angular contact design handles combined loads efficiently. Its brass cage ensures smooth operation even under high radial forces.
Where Is 7314 BECBY Bearing Used?
In automotive applications, 7314 BECBY Bearing is found in wheel hubs and transmissions, providing reliable performance under angular loads. The P6 tolerance class makes it suitable for precision automotive components.
Built for Heavy-Duty Use: 7314 BECBY Bearing
For heavy machinery, 7314 BECBY Bearing offers durability with its chrome steel construction, ideal for construction equipment. The 40° contact angle enhances its load-bearing capacity in demanding environments.
Automotive vs Aerospace: Applications of 7314 BECBY Bearing
While 7314 BECBY Bearing is popular in automotive systems, it also suits aerospace applications like actuator mechanisms. Its high dynamic radial load rating ensures performance in both fields.
Perfect Fit for Automation: 7314 BECBY Bearing
In robotics, 7314 BECBY Bearing supports precise movements in robotic arms and automated systems. The lubricated design reduces friction, extending service life in continuous operation.
