Single Row Angular Contact Ball Bearings (General) 7313 BEGBY
Single Row Angular Contact Ball Bearings (General) 7313 BEGBY

Single Row Angular Contact Ball Bearings (General) 7313 BEGBY

The 7313 BEGBY is a single-row angular contact ball bearing with a 65mm bore and 140mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 26100 lbf and operates smoothly at speeds up to 6300 RPM.

With a 40° contact angle, it efficiently handles combined radial and axial loads. The brass cage enhances durability, while the open design simplifies lubrication.

This bearing fits well in high-precision applications like pumps or gearboxes, thanks to its P6 tolerance class. It performs reliably in temperatures from -30°C to 110°C.

Weighing 2.15kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a dependable choice for industrial use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 7313 BEGBY
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 140 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 33 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 94.15 mm
  • External Diameter On Inner Ring (Small Side Face) 78.45 mm
  • Internal Diameter On Outer Ring 112.85 mm
  • Chamfer Dimension 2.1 mm
  • Distance Pressure Point (a) 60 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 26100 lbf
  • Static Radial Load 19462 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 6300 rpm
  • Weight 2.15 kg
  • Price($) 54.78

Features

Performance Features of 7313 BEGBY Bearing

7313 BEGBY Bearing is crafted with a 40° contact angle, ideal for handling combined radial and axial loads.
Its chrome steel rings and balls provide strength, while the brass cage ensures smooth operation.

The dynamic radial load capacity of 26100 lbf makes 7313 BEGBY Bearing suitable for demanding applications.
With a maximum speed of 6,300 rpm, it balances performance and durability.

7313 BEGBY Bearing operates efficiently within a temperature range of -30° to 110°C.
Its open design allows for easy lubrication, ensuring long service life.

The P6 tolerance class ensures precision, making 7313 BEGBY Bearing reliable for various industrial uses.
Its dimensions (65 mm×140 mm×33 mm) are optimised for space-saving installations.

Application

Industrial Uses of 7313 BEGBY Bearing
The 7313 BEGBY Bearing is commonly used in machine tools, where its angular contact design handles combined radial and axial loads efficiently. The brass cage ensures smooth operation even at moderate speeds.

In automotive applications, 7313 BEGBY Bearing fits well in wheel hubs and transmissions, thanks to its 40° contact angle. Its P6 tolerance class provides the precision needed for reliable performance.

For automation systems, 7313 BEGBY Bearing works effectively in robotic arms, offering stability under varying loads. The chrome steel construction adds durability for long-term use in demanding environments.

Medical imaging devices benefit from 7313 BEGBY Bearing’s consistent performance, where low noise and smooth rotation are essential. The lubricated design reduces maintenance needs in critical applications.

In household appliances like washing machines, 7313 BEGBY Bearing supports rotating drums with minimal vibration. Its metric sizing makes it compatible with a range of European-designed equipment.
