The 7312 BEP is a single-row angular contact ball bearing with a 60mm bore and 130mm outer diameter, crafted from sturdy chrome steel. Its 40° contact angle efficiently manages combined radial and axial loads, supporting up to 21510 lbf dynamically.
The nylon cage reduces friction, allowing smooth operation at speeds up to 6000 RPM. Open design simplifies lubrication, while the P6 tolerance ensures reliable precision in demanding conditions.
This bearing suits applications like pumps or gearboxes where angular loads are present. It’s interchangeable with SKF models, offering a practical replacement option. Compliant with RoHS and REACH standards, it operates in temperatures from -30°C to 110°C.
Weighing 1.75kg, it balances durability with manageable handling. The chamfered edges (2.1mm) ease installation, making it a practical choice for maintenance tasks.
"*" indicates required fields
Why Choose 7312 BEP Bearing for Precision Tasks?
7312 BEP Bearing features a 40° contact angle, optimised for handling combined radial and axial loads with precision.
Its chrome steel rings and balls ensure durability, while the nylon cage reduces friction for smoother operation.
The bearing’s P6 tolerance class (ABEC-3) guarantees consistent performance in high-precision applications.
With a dynamic radial load capacity of 21510 lbf, it reliably supports demanding industrial operations.
7312 BEP Bearing operates efficiently at speeds up to 6,000 rpm, maintaining stability across its temperature range.
Its open design allows for easy lubrication, extending service life and reducing maintenance needs.
Industrial Uses of 7312 BEP Bearing
7312 BEP Bearing is commonly used in industrial machinery like pumps and compressors, where its angular contact design handles combined loads efficiently. The open seal type allows for easy lubrication, extending service life in demanding conditions.
What Makes 7312 BEP Bearing a Preferred Choice?
In automotive applications, 7312 BEP Bearing supports wheel hubs and transmissions, thanks to its high dynamic radial load capacity. The chrome steel construction ensures durability even under continuous stress.
Perfect Fit for Automation: 7312 BEP Bearing
7312 BEP Bearing works well in robotic arms and automated systems, where precision and reliability are key. Its nylon cage reduces friction, making it ideal for high-speed operations.
Medical vs Industrial: Where 7312 BEP Bearing Excels
While 7312 BEP Bearing is robust enough for industrial gear, it also meets the precision needs of medical devices like centrifuges. The P6 tolerance class ensures consistent performance in sensitive environments.
Light-Duty vs Heavy-Duty: Best Uses for 7312 BEP Bearing
7312 BEP Bearing adapts to both light-duty applications like small motors and heavy-duty uses such as agricultural machinery. Its 40° contact angle provides excellent load distribution.
