Single Row Angular Contact Ball Bearings (General) 7216 BEGAPH
Single Row Angular Contact Ball Bearings (General) 7216 BEGAPH

Single Row Angular Contact Ball Bearings (General) 7216 BEGAPH

The 7216 BEGAPH is a single-row angular contact ball bearing with an 80mm bore and 140mm outer diameter, crafted from sturdy chrome steel. Its 40° contact angle efficiently handles combined radial and axial loads, supporting up to 19125 lbf dynamically.

The open design allows easy lubrication, while the nylon cage reduces friction for smoother rotation at speeds up to 5600 RPM. The P6 tolerance class ensures reliable precision in demanding conditions.

This bearing suits applications like pumps or gearboxes where angular loads are present. It operates well in temperatures from -30°C to 110°C and is interchangeable with SKF models for convenient replacements.

Weighing 1.45kg, it balances durability with manageable size. Compliant with RoHS and REACH standards, it’s a practical choice for industrial use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 7216 BEGAPH
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 80 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 140 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 26 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 103.55 mm
  • External Diameter On Inner Ring (Small Side Face) 91.44 mm
  • Internal Diameter On Outer Ring 117.85 mm
  • Chamfer Dimension 2 mm
  • Distance Pressure Point (a) 59 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 19125 lbf
  • Static Radial Load 16875 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 5600 rpm
  • Weight 1.45 kg

Features

Performance Features of 7216 BEGAPH Bearing

7216 BEGAPH Bearing is built with a 40° contact angle, ideal for handling combined radial and axial loads.
Its chrome steel rings and balls provide strength, while the nylon cage reduces friction and noise.

The bearing supports dynamic radial loads up to 19125 lbf, ensuring reliable performance in demanding applications.
With a maximum speed of 5,600 rpm, it balances efficiency and durability.

Designed for open lubrication, 7216 BEGAPH Bearing operates smoothly in temperatures from -30° to 110°C.
Its P6 tolerance class ensures precision, making it suitable for high-accuracy machinery.

The lightweight design at 1.45 kg simplifies installation without compromising performance.
Its dimensions (80 mm×140 mm×26 mm) make it versatile for various industrial uses.

Application

Industrial Uses of 7216 BEGAPH Bearing
The 7216 BEGAPH Bearing is commonly used in machine tools, where its 40° contact angle efficiently handles combined radial and axial loads. Its open design and nylon cage make it suitable for high-speed operations in industrial settings.

Where Is 7216 BEGAPH Bearing Used?
You’ll find 7216 BEGAPH Bearing in automotive transmissions, supporting smooth gear shifts with its angular contact design. The chrome steel construction ensures durability even under continuous stress.

Perfect Fit for Automation: 7216 BEGAPH Bearing
In robotic arms, 7216 BEGAPH Bearing provides precise movement thanks to its P6 tolerance class. The lubricated design reduces friction, extending the bearing’s lifespan in automated systems.

Medical vs Industrial: Where 7216 BEGAPH Bearing Excels
While 7216 BEGAPH Bearing performs well in industrial pumps, its precision also benefits medical imaging devices. The balanced load capacity makes it versatile across different applications.

How Does 7216 BEGAPH Bearing Support High-Speed Operations?
With a max speed of 5,600 rpm, 7216 BEGAPH Bearing is ideal for spindle applications in milling machines. The nylon cage helps maintain stability and reduces vibration during high-speed rotation.
