Single Row Angular Contact Ball Bearings (General) 7215 BEGAP
Single Row Angular Contact Ball Bearings (General) 7215 BEGAP

Single Row Angular Contact Ball Bearings (General) 7215 BEGAP

The 7215 BEGAP is a single-row angular contact ball bearing with a 75mm bore and 130mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 16538 lbf and operates smoothly at speeds up to 6300 RPM.

With a 40° contact angle, it efficiently manages combined loads, while the nylon cage reduces friction for quieter performance. Its open design allows easy lubrication and maintenance.

This bearing suits applications like pumps or gearboxes where angular contact is needed. It’s compatible with SKF models for straightforward replacements. Weighing 1.2kg, it’s robust yet manageable for industrial use.

Compliant with RoHS and REACH standards, it works in temperatures from -30°C to 110°C. The P6 tolerance class ensures reliable precision in demanding settings.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 7215 BEGAP
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 75 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 130 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 25 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 96.3 mm
  • External Diameter On Inner Ring (Small Side Face) 85.25 mm
  • Internal Diameter On Outer Ring 110.1 mm
  • Chamfer Dimension 1.5 mm
  • Distance Pressure Point (a) 56 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 16538 lbf
  • Static Radial Load 14738 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 6300 rpm
  • Weight 1.2 kg

Features

Performance Features of 7215 BEGAP Bearing

7215 BEGAP Bearing is designed with a 40° contact angle, ideal for handling combined radial and axial loads.
Its chrome steel rings and balls provide strong resistance to wear, ensuring reliable performance under heavy loads.

The nylon cage in 7215 BEGAP Bearing helps reduce friction and noise, making it suitable for precision applications.
With a dynamic radial load capacity of 16538 lbf, it delivers consistent performance in demanding conditions.

7215 BEGAP Bearing operates smoothly at speeds up to 6,300 rpm, balancing efficiency and durability.
Its P6 tolerance class ensures high precision, making it a dependable choice for various industrial uses.

Application

Industrial Uses of 7215 BEGAP Bearing
The 7215 BEGAP Bearing is commonly used in machine tools, where its 40° contact angle efficiently handles combined radial and axial loads. Its open design and nylon cage make it suitable for high-speed operations with minimal friction.

Where Is 7215 BEGAP Bearing Used?
You’ll often find 7215 BEGAP Bearing in automotive transmissions, supporting smooth gear shifts under angular loads. Its chrome steel construction ensures durability in demanding driving conditions.

Built for Heavy-Duty Use: 7215 BEGAP Bearing
7215 BEGAP Bearing works well in conveyor systems, managing heavy loads while maintaining precision. The P6 tolerance class guarantees consistent performance in industrial settings.

Automotive vs Aerospace: Applications of 7215 BEGAP Bearing
In cars, 7215 BEGAP Bearing handles wheel hub loads, while in aircraft, it supports auxiliary systems. Its metric sizing makes it versatile for different engineering standards.

Perfect Fit for Automation: 7215 BEGAP Bearing
7215 BEGAP Bearing excels in robotic arms, where its angular contact design enables precise movement. The lubricated construction ensures long service life in continuous operation.
