The 7214 BEGAM is a single-row angular contact ball bearing with a 70mm bore and 125mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 16200 lbf and operates smoothly at speeds up to 8000 RPM.
With a 40° contact angle, it efficiently manages combined radial and axial loads. The brass cage enhances durability while the open design allows for easy lubrication.
This bearing is interchangeable with SKF models, making it a practical choice for replacements. Suitable for applications like pumps or gearboxes where angular contact is needed.
Weighing 1.1kg, it’s robust yet manageable in size. Compliant with RoHS and REACH standards, it’s safe for various industrial uses.
"*" indicates required fields
Performance Features of 7214 BEGAM Bearing
7214 BEGAM Bearing features a 40° contact angle, ideal for handling combined radial and axial loads.
Its chrome steel construction ensures durability and resistance to wear in demanding applications.
The brass cage maintains ball alignment, reducing friction and enhancing smooth operation.
With a dynamic radial load capacity of 16,200 lbf, it performs reliably under heavy loads.
7214 BEGAM Bearing operates efficiently at speeds up to 8,000 rpm, balancing speed and stability.
Its P6 tolerance class (ABEC-3) ensures precision for high-performance machinery.
Designed for a temperature range of -30° to 110°C, it adapts to various working conditions.
The open seal type allows for easy lubrication, extending maintenance intervals.
Industrial Uses of 7214 BEGAM Bearing
The 7214 BEGAM Bearing is commonly used in machine tools, where its angular contact design handles combined radial and axial loads efficiently. The brass cage ensures smooth operation even at higher speeds, making it suitable for precision equipment.
In automotive applications, 7214 BEGAM Bearing works well in wheel hubs and gearboxes, thanks to its robust chrome steel construction. The 40° contact angle provides excellent stability under varying load conditions.
For automation systems, 7214 BEGAM Bearing supports robotic arms and conveyor belts, where its P6 tolerance class ensures reliable performance. The open seal design allows for easy lubrication, extending its service life.
In household appliances like washing machines, 7214 BEGAM Bearing offers quiet and durable operation. Its metric sizing makes it a versatile choice for various European and Asian brands.
