Single Row Angular Contact Ball Bearings (General) 7214 BEGAF
Single Row Angular Contact Ball Bearings (General) 7214 BEGAF

Single Row Angular Contact Ball Bearings (General) 7214 BEGAF

The 7214 BEGAF is a single-row angular contact ball bearing with a 70mm bore and 125mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 15210 lbf and operates smoothly at speeds up to 6000 RPM.

With a 40° contact angle, it efficiently manages combined radial and axial loads. The open design allows easy lubrication, while the stainless steel cage ensures durability.

This bearing is interchangeable with SKF models, making it a practical choice for replacements. Suitable for gearboxes, pumps, or machinery requiring precise angular contact performance.

Weighing 1.1kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s safe for use in temperatures from -30°C to 110°C.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 7214 BEGAF
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 70 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 125 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 24 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 91.5 mm
  • External Diameter On Inner Ring (Small Side Face) 80.25 mm
  • Internal Diameter On Outer Ring 104.75 mm
  • Chamfer Dimension 1.5 mm
  • Distance Pressure Point (a) 53 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 15210 lbf
  • Static Radial Load 12600 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 6000 rpm
  • Weight 1.1 kg

Features

Performance Features of 7214 BEGAF Bearing

7214 BEGAF Bearing is designed with a 40° contact angle, ideal for handling combined radial and axial loads.
Its chrome steel construction ensures durability and resistance to wear in demanding applications.

The stainless steel cage maintains ball alignment, reducing friction and extending operational life.
With a dynamic radial load capacity of 15210 lbf, it performs reliably under heavy loads.

7214 BEGAF Bearing operates efficiently at speeds up to 6,000 rpm, balancing performance and longevity.
Its open design allows for easy lubrication, ensuring smooth operation in various conditions.

The bearing’s P6 tolerance class (ABEC-3) guarantees precision and consistent performance.
It functions well in temperatures ranging from -30° to 110°C, suitable for diverse environments.

Application

Industrial Uses of 7214 BEGAF Bearing
The 7214 BEGAF Bearing is commonly used in machine tools, where its 40° contact angle efficiently handles combined radial and axial loads. Its open design and chrome steel construction ensure durability in demanding industrial environments.

In automotive applications, 7214 BEGAF Bearing supports high-performance gearboxes and wheel hubs, providing smooth operation under heavy loads. The metric sizing and P6 tolerance make it a reliable choice for precision automotive components.

For automation systems, 7214 BEGAF Bearing is ideal for robotic arms and CNC machinery, thanks to its high-speed capability and stainless steel cage. The consistent performance ensures minimal downtime in automated production lines.

Medical imaging devices benefit from 7214 BEGAF Bearing’s precise angular contact and low friction. Its reliable operation is crucial for maintaining accuracy in diagnostic equipment like MRI scanners.

In household appliances like washing machines, 7214 BEGAF Bearing offers quiet and efficient performance. The lubricated design reduces wear, extending the lifespan of everyday devices.
