Single Row Angular Contact Ball Bearings (General) 7214 BECBP
Single Row Angular Contact Ball Bearings (General) 7214 BECBP

Single Row Angular Contact Ball Bearings (General) 7214 BECBP

The 7214 BECBP is a single-row angular contact ball bearing with a 70mm bore and 125mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 16200 lbf and operates smoothly at speeds up to 6300 RPM.

Its 40° contact angle efficiently handles combined loads, while the open design allows for easy lubrication. The nylon cage reduces friction and noise, enhancing performance.

This bearing suits applications with angular loads, such as pumps or gearboxes. It works reliably in temperatures from -30°C to 110°C.

Weighing 1.1kg, it’s a robust choice for industrial machinery. Compliant with RoHS and REACH standards, it’s interchangeable with SKF models for easy replacement.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 7214 BECBP
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 70 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 125 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 24 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 91.5 mm
  • External Diameter On Inner Ring (Small Side Face) 80.25 mm
  • Internal Diameter On Outer Ring 104.75 mm
  • Chamfer Dimension 1.5 mm
  • Distance Pressure Point (a) 53 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 16200 lbf
  • Static Radial Load 13500 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 6300 rpm
  • Weight 1.1 kg
  • Price($) 58.44

Features

Performance Features of 7214 BECBP Bearing

7214 BECBP Bearing is built with a 40° contact angle, ideal for handling combined radial and axial loads.
Its chrome steel rings and balls provide strong resistance to wear, ensuring long-lasting performance.

The nylon cage in 7214 BECBP Bearing reduces friction and noise, making it suitable for precision applications.
With a dynamic radial load capacity of 16,200 lbf, it performs reliably under heavy loads.

7214 BECBP Bearing operates smoothly at speeds up to 6,300 rpm, balancing efficiency and durability.
Its P6 tolerance class ensures consistent performance in demanding conditions.

Application

Industrial Uses of 7214 BECBP Bearing
The 7214 BECBP Bearing is commonly used in machine tools, where its 40° contact angle efficiently handles combined radial and axial loads. The open design and nylon cage reduce friction, making it suitable for high-speed operations.

In automotive applications, 7214 BECBP Bearing works well in wheel hubs and transmissions, thanks to its robust chrome steel construction. The P6 tolerance ensures precise alignment, which is crucial for vehicle performance and safety.

For automation systems, 7214 BECBP Bearing supports robotic arms and conveyor belts, offering reliable performance under continuous use. Its lubricated design helps maintain smooth movement, even in demanding industrial environments.

Medical imaging devices also benefit from 7214 BECBP Bearing’s precision and durability. The chrome steel rings and nylon cage provide quiet operation, essential for sensitive diagnostic equipment.

In household appliances like washing machines, 7214 BECBP Bearing ensures long-lasting performance. The metric sizing and balanced load capacity make it a versatile choice for various consumer products.
