The 7214 BECBM is a single-row angular contact ball bearing with a 70mm bore and 125mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 16200 lbf and operates smoothly at speeds reaching 8000 RPM.
With a 40° contact angle, it efficiently handles combined radial and axial loads. The brass cage enhances durability, while the open design simplifies lubrication and maintenance.
This bearing is interchangeable with SKF models, making it a versatile replacement option. Suitable for gearboxes, pumps, or machinery requiring precise angular contact performance.
Weighing 1.1kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it works reliably in temperatures from -30°C to 110°C.
"*" indicates required fields
Performance Features of 7214 BECBM Bearing
7214 BECBM Bearing is designed with a 40° contact angle, optimising its ability to handle combined radial and axial loads.
The chrome steel rings and balls ensure durability, while the brass cage maintains smooth operation.
With a dynamic radial load capacity of 16,200 lbf, 7214 BECBM Bearing performs reliably under heavy loads.
Its P6 tolerance class (ABEC-3) ensures precision, making it suitable for high-performance applications.
7214 BECBM Bearing operates efficiently at speeds up to 8,000 rpm, balancing speed and load capacity.
The open design allows for easy lubrication, enhancing its performance in various conditions.
The temperature range of -30° to 110°C ensures 7214 BECBM Bearing works well in diverse environments.
Its robust construction and precise engineering make it a dependable choice for demanding tasks.
Industrial Uses of 7214 BECBM Bearing
The 7214 BECBM Bearing is commonly used in machine tools, where its 40° contact angle efficiently handles combined radial and axial loads. Its brass cage ensures smooth operation even at high speeds, making it suitable for precision machining.
In automotive applications, 7214 BECBM Bearing supports components like wheel hubs and transmissions, thanks to its robust chrome steel construction. The P6 tolerance class provides the accuracy needed for reliable performance in demanding conditions.
For automation systems, 7214 BECBM Bearing is a solid choice for robotic arms and conveyor belts, where its angular contact design improves stability. The open seal type allows for easy lubrication, extending its service life in continuous operations.
Medical imaging devices benefit from 7214 BECBM Bearing’s consistent performance and low noise levels. Its temperature range of -30° to 110°C ensures reliability in various clinical environments.
In household appliances like washing machines, 7214 BECBM Bearing’s durability and smooth operation reduce wear and tear. The metric sizing makes it compatible with a wide range of consumer products.
