The 7207 BEGBY is a single-row angular contact ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 6975 lbf and spins smoothly at speeds up to 12,000 RPM.
Its 40° contact angle efficiently manages combined loads, while the brass cage ensures durability and quiet operation. The open design allows for easy lubrication and maintenance.
This bearing suits applications like pumps or gearboxes where angular loads are present. With a temperature range of -30°C to 110°C, it performs reliably in various conditions.
Weighing 0.28kg, it’s a robust yet lightweight option. Compliant with RoHS and REACH standards, it’s also interchangeable with SKF bearings for easy replacement.
"*" indicates required fields
Performance Features of 7207 BEGBY Bearing
7207 BEGBY Bearing features a 40° contact angle, optimised for handling combined radial and axial loads.
Its chrome steel rings and balls provide strength, while the brass cage ensures smooth operation at high speeds.
With a dynamic radial load capacity of 6975 lbf, 7207 BEGBY Bearing performs reliably under heavy loads.
The P6 tolerance class ensures precision, making it suitable for applications requiring accurate alignment.
7207 BEGBY Bearing operates efficiently at speeds up to 12,000 rpm, maintaining stability.
Its open design allows for easy lubrication, extending service life in various conditions.
Industrial Uses of 7207 BEGBY Bearing
7207 BEGBY Bearing is commonly used in machine tools, where its 40° contact angle efficiently handles combined radial and axial loads. The brass cage ensures smooth operation at high speeds, making it suitable for precision machining.
In automotive applications, 7207 BEGBY Bearing supports gearbox systems, providing reliable performance under angular loads. Its P6 tolerance class ensures consistent alignment, which is crucial for vehicle drivetrains.
For automation equipment, 7207 BEGBY Bearing is a solid choice for robotic arms due to its high-speed capability and durability. The open design allows for easy lubrication, extending service life in continuous operation.
Where Is 7207 BEGBY Bearing Used?
You’ll often find 7207 BEGBY Bearing in conveyor systems, where its chrome steel construction withstands heavy loads. The metric sizing makes it compatible with a wide range of industrial machinery.
In medical imaging devices, 7207 BEGBY Bearing offers quiet and precise rotation. Its temperature range of -30° to 110 °C ensures reliability in various clinical environments.
Built for Heavy-Duty Use: 7207 BEGBY Bearing
7207 BEGBY Bearing excels in pump applications, handling both radial and thrust loads with ease. The lubricated design reduces friction, making it ideal for continuous operation.
For electric motors, 7207 BEGBY Bearing provides stable performance at speeds up to 12,000 rpm. Its brass cage minimizes vibration, ensuring smooth and efficient power transmission.
