Self Aligning Ball Bearings 2309 M/VQ335
Self Aligning Ball Bearings 2309 M/VQ335

Self Aligning Ball Bearings 2309 M/VQ335

The 2309 M/VQ335 is a self-aligning ball bearing with a 45mm bore and 100mm outer diameter, crafted from sturdy chrome steel. Its double-row design and sealed construction help it manage radial loads up to 8775 lbf while running smoothly at 4300 RPM.

The brass cage reduces friction, and the lubricated setup ensures quiet operation. It works in temperatures from -30°C to 110°C, making it versatile for various environments.

This model aligns itself to minor misalignments, reducing wear. It’s interchangeable with SKF bearings, ideal for heavy-duty applications like conveyor systems or agricultural machinery.

Weighing 1.3kg, it’s robust yet manageable. Compliant with RoHS and REACH standards, it’s a reliable choice for industrial use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 2309 M/VQ335
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 45 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 36 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 60.9 mm
  • Internal Diameter On Outer Ring 90 mm
  • Chamfer Dimension 1.5 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 8775 lbf
  • Static Radial Load 3015 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4300 rpm
  • Weight 1.3 kg
  • Price($) 218.25

Features

How Is 2309 M/VQ335 Bearing Engineered for Reliability?

2309 M/VQ335 Bearing features a double-row design with chrome steel rings and balls, ensuring strong radial load capacity.
Its dynamic radial load reaches 8775 lbf, making it suitable for demanding applications.
The brass cage maintains ball alignment, reducing friction and wear for smoother operation.
With a maximum speed of 4,300 rpm, it balances performance and durability in various conditions.

Application

Industrial Uses of 2309 M/VQ335 Bearing
2309 M/VQ335 Bearing is commonly used in industrial machinery like conveyor belts and heavy-duty fans, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, extending service life in dusty environments.

What Makes 2309 M/VQ335 Bearing a Preferred Choice?
In automotive applications, 2309 M/VQ335 Bearing fits well in wheel hubs and transmission systems, thanks to its double-row construction for handling radial loads. The brass cage adds durability, making it reliable for long-term use.

Perfect Fit for Automation: 2309 M/VQ335 Bearing
For robotic arms and automated assembly lines, 2309 M/VQ335 Bearing offers smooth rotation and low maintenance. Its lubricated design ensures consistent performance even in high-speed operations.

Medical vs Industrial: Where 2309 M/VQ335 Bearing Excels
While 2309 M/VQ335 Bearing suits industrial gear like pumps, its precision also benefits medical imaging devices. The chrome steel rings provide stability, crucial for sensitive equipment.

Essential Roles of 2309 M/VQ335 Bearing
In household appliances like washing machines, 2309 M/VQ335 Bearing reduces vibration and noise. The metric sizing ensures easy replacement in European and Asian models.
