Self Aligning Ball Bearings 2305 M C/3
Self Aligning Ball Bearings 2305 M C/3

Self Aligning Ball Bearings 2305 M C/3

The 2305 M C/3 is a self-aligning ball bearing with a 25mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 5445 lbf and operates smoothly at speeds up to 16,000 RPM.

Its double-row design and brass cage provide reliable performance, while the open seal allows for easy lubrication. The bearing works efficiently in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like conveyor systems or agricultural machinery where alignment flexibility is needed.

Weighing 0.37kg, it offers a balance of strength and lightweight design. Compliant with RoHS and REACH standards for safe usage.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 2305 M C/3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 24 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 35.5 mm
  • Internal Diameter On Outer Ring 50.6 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 5445 lbf
  • Static Radial Load 1474 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 16000 rpm
  • Weight 0.37 kg
  • Price($) 109.5

Features

Why Choose 2305 M C/3 Bearing for Precision Tasks?

2305 M C/3 Bearing features a double-row design, offering excellent radial load capacity up to 5445 lbf.
Its chrome steel rings and balls ensure durability and smooth operation in various applications.

The brass cage maintains ball alignment, reducing friction and extending the bearing’s life.
With a maximum speed of 16,000 rpm, it is suitable for high-speed operations.

2305 M C/3 Bearing operates efficiently within a temperature range of -30° to 110°C.
Its open design allows for easy lubrication, ensuring consistent performance over time.

Application

Industrial Uses of 2305 M C/3 Bearing
The 2305 M C/3 Bearing is commonly used in conveyor systems and industrial fans, where its self-aligning feature compensates for minor misalignments. Its double-row design ensures stable performance under radial loads, making it suitable for continuous operation.

In automotive applications, 2305 M C/3 Bearing fits well in gearboxes and drive shafts, providing smooth rotation even under varying loads. The brass cage enhances durability, making it a reliable choice for long-term use.

For automation equipment like robotic arms, 2305 M C/3 Bearing offers precise movement thanks to its chrome steel construction. The open seal design allows for easy lubrication, ensuring consistent performance in high-speed scenarios.

Where Is 2305 M C/3 Bearing Used?
You’ll often find 2305 M C/3 Bearing in household appliances like washing machines, where its self-aligning capability reduces wear and tear. The metric sizing ensures compatibility with a wide range of consumer products.

In medical devices such as lab centrifuges, 2305 M C/3 Bearing’s reliable performance and low maintenance make it a practical choice. The temperature range of -30° to 110°C ensures it can handle various operating conditions.
