Self Aligning Ball Bearings 2207 2RS
Self Aligning Ball Bearings 2207 2RS

Self Aligning Ball Bearings 2207 2RS

The 2207 2RS is a self-aligning ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 4275 lbf and operates smoothly at speeds up to 6300 RPM.

Its double-row design and sealed construction help maintain alignment and keep dirt out, while the nylon cage reduces friction. The bearing comes pre-lubricated for easy installation.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing 0.41kg, it’s durable yet manageable. Compliant with RoHS and REACH standards, it works in temperatures from -30°C to 110°C.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 2207 2RS
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 23 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 42.7 mm
  • Internal Diameter On Outer Ring 62.69 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 4275 lbf
  • Static Radial Load 1350 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 6300 rpm
  • Weight 0.41 kg
  • Price($) 45.09

Features

Why Choose 2207 2RS Bearing for Precision Tasks?

2207 2RS Bearing features a double-row ball design, ensuring smooth radial load distribution.
Its chrome steel rings and balls enhance durability, while the nylon cage reduces friction.
The sealed construction keeps contaminants out, making it ideal for harsh environments.
With a dynamic radial load capacity of 4275 lbf, it handles demanding applications with ease.

How Is 2207 2RS Bearing Engineered for Reliability?

2207 2RS Bearing’s cylindrical bore design ensures a secure fit, minimising misalignment issues.
The chrome steel construction resists wear, extending the bearing’s service life.
Its sealed design protects against dust and moisture, reducing maintenance needs.
With a maximum speed of 6,300 rpm, it delivers consistent performance under various conditions.

Built for Durability: 2207 2RS Bearing

2207 2RS Bearing’s double-row design provides excellent load-carrying capacity for radial applications.
The nylon cage ensures quiet operation and reduces friction, enhancing efficiency.
Its sealed construction prevents lubricant leakage and keeps contaminants out.
Operating within a temperature range of -30° to 110°C, it performs reliably in diverse environments.

Steel vs Ceramic Bearings: Strengths of 2207 2RS Bearing

2207 2RS Bearing uses chrome steel for both rings and balls, offering a balance of strength and affordability.
The nylon cage reduces weight and noise compared to metal cages, improving performance.
Its sealed design provides better protection against contaminants than open bearings.
With a dynamic radial load rating of 4275 lbf, it suits a wide range of industrial applications.

Performance Features of 2207 2RS Bearing

2207 2RS Bearing’s double-row construction allows for higher load capacity in a compact size.
The precision-ground chrome steel components ensure smooth operation and long service life.
Its sealed design maintains lubrication and prevents contamination, reducing downtime.
With a maximum speed of 6,300 rpm, it delivers reliable performance in various machinery.

Application

Industrial Uses of 2207 2RS Bearing
2207 2RS Bearing is commonly used in industrial settings, especially in machinery that requires smooth radial load handling, like conveyor belts and pumps. Its sealed design helps keep contaminants out, making it reliable in dusty or wet environments.

In automotive applications, 2207 2RS Bearing works well in components like wheel hubs and transmissions, where its double-row construction provides stability. The metric sizing ensures compatibility with various vehicle designs, both in Europe and Asia.

For automation systems, 2207 2RS Bearing’s nylon cage reduces friction, making it suitable for robotic arms and assembly lines. The chrome steel rings also contribute to its long-lasting performance in high-speed operations.

Around the home, 2207 2RS Bearing can be found in appliances like washing machines, where its sealed design prevents grease leakage. The lubricated build ensures quiet and efficient operation over time.
