Self Aligning Ball Bearings 2205 M
Self Aligning Ball Bearings 2205 M

Self Aligning Ball Bearings 2205 M

The 2205 M is a self-aligning ball bearing with a 25mm bore and 52mm outer diameter, crafted from sturdy chrome steel. Its compact width of 18mm makes it suitable for tight spaces while handling radial loads up to 3218 lbf.

The double-row design and brass cage ensure smooth operation at speeds up to 9000 RPM, even in misaligned conditions. Sealed construction keeps lubrication intact and shields against contaminants.

Pre-lubricated for easy use, it performs reliably in temperatures from -30°C to 110°C. This model is interchangeable with SKF bearings, offering a practical replacement option.

Ideal for applications like conveyor systems or agricultural machinery where alignment flexibility is needed. Weighing just 0.16kg, it’s a lightweight yet durable choice for industrial settings. Compliant with RoHS and REACH standards.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 2205 M
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 18 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 31 mm
  • Internal Diameter On Outer Ring 46.21 mm
  • Chamfer Dimension 1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 3218 lbf
  • Static Radial Load 900 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 9000 rpm
  • Weight 0.16 kg
  • Price($) 51.41

Features

How Does 2205 M Bearing Reduce Friction?

2205 M Bearing features a double-row design with chrome steel balls, ensuring smooth radial load distribution.
Its brass cage maintains proper ball alignment, reducing friction and wear during operation.
The sealed construction keeps lubrication intact, enhancing performance and longevity.
With a maximum speed of 9,000 rpm, it offers reliable efficiency in various applications.

Built for Reliability: 2205 M Bearing

2205 M Bearing is crafted with chrome steel rings and balls for consistent performance under radial loads.
The double-row construction and brass cage provide stability, minimising vibration and noise.
Its sealed design protects against contaminants, ensuring smooth operation in harsh conditions.
With a dynamic radial load capacity of 3218 lbf, it delivers dependable service over time.

Technical Highlights of 2205 M Bearing

2205 M Bearing’s cylindrical bore design ensures easy installation and precise alignment.
The chrome steel components resist wear, while the brass cage enhances durability and reduces friction.
Its sealed construction maintains lubrication, extending maintenance intervals.
Operating between -30° to 110°C, it performs reliably in diverse environments.

Application

Industrial Uses of 2205 M Bearing
2205 M Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. The sealed design helps keep contaminants out, ensuring longer service life in dusty environments.

In automotive applications, 2205 M Bearing fits well in wheel hubs and transmission systems, providing smooth radial load support. Its brass cage adds durability, making it suitable for high-vibration conditions.

For robotics, 2205 M Bearing’s double-row construction offers stability in articulated joints and rotating arms. The lubricated design reduces friction, which is key for precision movements in automated systems.

Medical imaging devices benefit from 2205 M Bearing’s consistent performance and low maintenance needs. The chrome steel rings and balls ensure reliability in critical diagnostic equipment.

Household appliances like washing machines often use 2205 M Bearing for its quiet operation and resistance to wear. The metric sizing makes it easy to replace in European and Asian models.
