Self Aligning Ball Bearings 2205-2RSTNGC3
Self Aligning Ball Bearings 2205-2RSTNGC3

Self Aligning Ball Bearings 2205-2RSTNGC3

The 2205-2RSTNGC3 is a self-aligning ball bearing with a 25mm bore and 52mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 3218 lbf and operates smoothly at speeds up to 9000 RPM.
Its sealed design keeps lubrication in and contaminants out, while the nylon cage reduces friction for quieter performance. The bearing works reliably in temperatures from -30°C to 110°C.
This model is interchangeable with SKF bearings, offering a practical replacement option. Perfect for machinery with slight misalignments, like conveyor systems or agricultural equipment.
Weighing just 0.16kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 2205-2RSTNGC3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 18 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 31 mm
  • Internal Diameter On Outer Ring 46.21 mm
  • Chamfer Dimension 1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 3218 lbf
  • Static Radial Load 900 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 9000 rpm
  • Weight 0.16 kg

Features

Why Choose 2205-2RSTNGC3 Bearing for Precision Tasks?

2205-2RSTNGC3 Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 3218 lbf makes it suitable for demanding applications.

The sealed construction and nylon cage provide smooth operation while reducing maintenance needs.
With a maximum speed of 9,000 rpm, it offers both durability and efficiency.

2205-2RSTNGC3 Bearing operates in temperatures from -30° to 110°C, adapting to various environments.
Its C3 radial clearance ensures reliable performance under different load conditions.

Application

Common Applications of 2205-2RSTNGC3 Bearing
In industrial settings, 2205-2RSTNGC3 Bearing is a go-to for conveyor systems and pumps, thanks to its self-aligning feature that compensates for minor misalignments. The sealed design keeps contaminants out, extending its lifespan in dusty environments.

Where Is 2205-2RSTNGC3 Bearing Used?
You’ll often spot 2205-2RSTNGC3 Bearing in automotive applications like steering columns, where its radial load capacity and smooth operation are key. The nylon cage reduces friction, making it a quiet performer in vehicle systems.

Built for Heavy-Duty Use: 2205-2RSTNGC3 Bearing
This bearing shines in agricultural machinery, handling uneven loads with ease due to its double-row construction. The chrome steel rings and balls ensure durability even in tough conditions like harvesters or tractors.

Automotive vs Industrial: Where 2205-2RSTNGC3 Bearing Excels
While 2205-2RSTNGC3 Bearing works well in car transmissions, it’s equally at home in factory gearboxes. Its C3 clearance allows for thermal expansion, making it versatile across different operating temperatures.

Perfect Fit for Automation: 2205-2RSTNGC3 Bearing
In robotic arms, 2205-2RSTNGC3 Bearing offers reliable movement with its low-maintenance sealed design. The metric sizing ensures compatibility with precision equipment, from assembly lines to packaging machines.
