Self Aligning Ball Bearings 2205-2RS-TVH-C3
Self Aligning Ball Bearings 2205-2RS-TVH-C3

Self Aligning Ball Bearings 2205-2RS-TVH-C3

The 2205-2RS-TVH-C3 is a self-aligning ball bearing with a 25mm bore and 52mm outer diameter, compact at just 18mm wide. Made from chrome steel, it’s built to handle radial loads up to 3218 lbf and speeds of 9000 RPM.

Its double-row design and sealed construction help it stay aligned in misaligned shafts, while the nylon cage reduces noise and friction. The C3 radial clearance allows for thermal expansion in various conditions.

Pre-lubricated and ready to use, it works in temperatures from -30°C to 110°C. Ideal for applications like conveyor systems or electric motors where slight shaft misalignment may occur.

Weighing only 0.16kg, it’s a lightweight yet durable choice. Compliant with RoHS and REACH standards for safe and reliable performance.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 2205-2RS-TVH-C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 18 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 31 mm
  • Internal Diameter On Outer Ring 46.21 mm
  • Chamfer Dimension 1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 3218 lbf
  • Static Radial Load 900 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 9000 rpm
  • Weight 0.16 kg
  • Price($) 37.53

Features

Why Choose 2205-2RS-TVH-C3 Bearing for Precision Tasks?

2205-2RS-TVH-C3 Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 3218 lbf makes it suitable for high-performance applications.

The sealed construction and nylon cage provide smooth operation while keeping contaminants out.
With a maximum speed of 9,000 rpm, it balances efficiency and durability.

2205-2RS-TVH-C3 Bearing operates in temperatures from -30° to 110°C, adapting to various environments.
Its C3 radial clearance ensures reliable performance under varying load conditions.

Application

Industrial Uses of 2205-2RS-TVH-C3 Bearing
2205-2RS-TVH-C3 Bearing is commonly used in conveyor systems, where its self-aligning feature helps accommodate minor misalignments. The sealed design keeps contaminants out, ensuring longer service life in dusty environments.

In automotive applications, 2205-2RS-TVH-C3 Bearing fits well in wheel hubs and transmissions, providing smooth radial load support. Its nylon cage reduces noise, making it ideal for passenger vehicles.

For automation equipment, 2205-2RS-TVH-C3 Bearing’s double-row construction offers stability in robotic arms. The C3 clearance allows for thermal expansion, maintaining performance in varying temperatures.

Where Is 2205-2RS-TVH-C3 Bearing Used?
You’ll find 2205-2RS-TVH-C3 Bearing in industrial fans, where its sealed design protects against dust and moisture. The chrome steel construction ensures durability even in continuous operation.

In household appliances like washing machines, 2205-2RS-TVH-C3 Bearing handles radial loads with ease. The lubricated design means less maintenance, perfect for everyday use.

Built for Heavy-Duty Use: 2205-2RS-TVH-C3 Bearing
2205-2RS-TVH-C3 Bearing excels in construction equipment, where its robust design handles heavy radial loads. The self-aligning capability compensates for shaft deflections, reducing wear.

In agricultural machinery, 2205-2RS-TVH-C3 Bearing’s sealed construction prevents dirt ingress. This makes it reliable for tractors and harvesters operating in tough conditions.

Light-Duty vs Heavy-Duty: Best Uses for 2205-2RS-TVH-C3 Bearing
For light-duty tasks like office printers, 2205-2RS-TVH-C3 Bearing offers quiet operation. The nylon cage minimizes friction, extending the bearing’s lifespan.

In heavy-duty scenarios like mining equipment, 2205-2RS-TVH-C3 Bearing’s chrome steel rings withstand high loads. The C3 clearance ensures smooth performance under stress.
