Self Aligning Ball Bearings 1322 M
Self Aligning Ball Bearings 1322 M

Self Aligning Ball Bearings 1322 M

The 1322 M is a self-aligning ball bearing with a 110mm bore and 240mm outer diameter, crafted from sturdy chrome steel for reliable performance. Its double-row design helps manage radial loads up to 36675 lbf, while the nylon cage reduces friction for smoother operation.

This open-type bearing spins efficiently at speeds up to 3600 RPM and works in temperatures from -30°C to 110°C. Its self-aligning feature compensates for minor misalignments, making it easier to install in various setups.

Ideal for heavy-duty applications like conveyor systems or industrial fans, where radial loads and slight shaft misalignments are common. Weighing 12kg, it’s built to handle demanding environments while staying compliant with RoHS and REACH standards.

The bearing is interchangeable with SKF models, offering a practical replacement option. Its pre-lubricated design ensures ready-to-use convenience, saving time during installation.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 1322 M
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 110 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 240 mm
  • Outer Dia Tolerance -0.03mm to 0
  • Width 50 mm
  • Width Tolerance -0.2mm to 0
  • External Diameter On Inner Ring 154.35 mm
  • Internal Diameter On Outer Ring 202.9 mm
  • Chamfer Dimension 3 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 36675 lbf
  • Static Radial Load 16200 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 3600 rpm
  • Weight 12 kg
  • Price($) 597.65

Features

How Does 1322 M Bearing Handle Radial Loads?

1322 M Bearing features a double-row design with chrome steel rings and balls, optimised for high radial load capacity.
Its dynamic radial load reaches 36,675 lbf, making it suitable for heavy-duty industrial applications.
The nylon cage ensures smooth operation and reduces friction, enhancing efficiency.
With a maximum speed of 3,600 rpm, it balances performance and durability in demanding conditions.

Why Choose 1322 M Bearing for Precision Tasks?

1322 M Bearing’s precise bore and outer diameter tolerances ensure accurate alignment in machinery.
The chrome steel construction resists wear, maintaining performance over extended periods.
Its open design allows for easy lubrication, reducing maintenance requirements.
Operating between -30° to 110°C, it adapts well to varying environmental conditions.

Engineered for Reliability: 1322 M Bearing

1322 M Bearing’s robust chrome steel components provide long-lasting durability under heavy loads.
The double-row ball arrangement distributes forces evenly, minimising stress on individual components.
Weighing 12 kg, it offers a solid build without compromising on efficiency.
Its compliance with RoHS and REACH standards ensures environmental and safety adherence.

Application

Industrial Uses of 1322 M Bearing
1322 M Bearing is commonly used in heavy machinery like conveyor systems and industrial fans, where its self-aligning feature compensates for minor misalignments. The double-row design ensures stable performance under radial loads, making it suitable for demanding environments.

In automotive applications, 1322 M Bearing fits well in gearboxes and drivetrains, handling high radial loads with ease. Its chrome steel construction provides durability, while the nylon cage reduces friction for smoother operation.

For automation equipment, 1322 M Bearing supports robotic arms and assembly lines, where precision and reliability are key. The open seal design allows for easy lubrication, extending its service life in continuous-use scenarios.

Where Is 1322 M Bearing Used?
You’ll often find 1322 M Bearing in wind turbines, where its ability to handle misalignment and radial loads is crucial. The metric sizing ensures compatibility with a wide range of European-designed systems.

In construction machinery, 1322 M Bearing excels in equipment like cranes and excavators, thanks to its robust design. The lubricated construction helps maintain performance even under heavy loads and varying temperatures.
