Self Aligning Ball Bearings 1305KJ
Self Aligning Ball Bearings 1305KJ

Self Aligning Ball Bearings 1305KJ

The 1305KJ is a self-aligning ball bearing with a 25mm tapered bore and 62mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4275 lbf and operates smoothly at speeds up to 15,000 RPM.

Its double-row design allows slight misalignment adjustments, reducing wear in uneven setups. The open seal type makes lubrication straightforward, while the steel cage enhances durability.

This bearing suits environments with minor shaft misalignment, such as conveyor systems or agricultural machinery. It performs reliably in temperatures from -30°C to 110°C.

Weighing 0.26kg, it’s a robust yet lightweight option. Compliant with RoHS and REACH standards, it’s interchangeable with SKF models for easy replacement.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 1305KJ
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 38 mm
  • Internal Diameter On Outer Ring 50.7 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 4275 lbf
  • Static Radial Load 1215 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 15000 rpm
  • Weight 0.26 kg

Features

How Does 1305KJ Bearing Reduce Friction?

1305KJ Bearing features a double-row design with chrome steel balls, ensuring smooth radial load distribution.
Its precision-engineered taper bore minimises misalignment, reducing friction during operation.
The steel cage maintains ball alignment, enhancing durability and performance.
With a maximum speed of 15,000 rpm, it offers reliable efficiency in various applications.

Application

Industrial Uses of 1305KJ Bearing
1305KJ Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. The double-row design ensures stability even under varying radial loads.

In automotive applications, 1305KJ Bearing fits well in gearboxes and wheel hubs, thanks to its tapered bore for secure mounting. Its high-speed capability makes it suitable for both passenger and commercial vehicles.

For automation equipment, 1305KJ Bearing provides smooth operation in robotic arms and assembly lines. The open seal type allows for easy lubrication, extending service life in continuous-use environments.

Where Is 1305KJ Bearing Used?
You’ll find 1305KJ Bearing in industrial fans, where its chrome steel construction handles moderate radial loads efficiently. The lubricated design reduces friction, ensuring quiet operation.

In household appliances like washing machines, 1305KJ Bearing supports rotating drums with reliability. Its compact size and weight make it a practical choice for space-constrained designs.

Built for Heavy-Duty Use: 1305KJ Bearing
1305KJ Bearing excels in construction machinery, where its dynamic load capacity handles rough conditions. The steel cage adds durability, making it a dependable option for long-term use.

In agricultural equipment, 1305KJ Bearing withstands dust and debris while maintaining performance. Its temperature range ensures functionality in both hot and cold environments.

Automotive vs Aerospace: Applications of 1305KJ Bearing
In automotive systems, 1305KJ Bearing is ideal for transmissions due to its high-speed tolerance. The metric sizing ensures compatibility with global vehicle standards.

For aerospace components, 1305KJ Bearing offers precision in auxiliary systems. Its lightweight design and reliability meet the stringent demands of aviation applications.
