Self Aligning Ball Bearings 1217-TVH-C3
Self Aligning Ball Bearings 1217-TVH-C3

Self Aligning Ball Bearings 1217-TVH-C3

The 1217-TVH-C3 is a self-aligning ball bearing with an 85mm bore and 150mm outer diameter, crafted from sturdy chrome steel. Its double-row design helps manage radial loads up to 10980 lbf, while maintaining smooth operation at speeds up to 5600 RPM.

Featuring an open seal and nylon cage, it offers easy maintenance and reduced friction. The C3 radial clearance allows for slight misalignment, making it adaptable in less-than-perfect setups.

This bearing is pre-lubricated and performs reliably in temperatures from -30°C to 110°C. It’s interchangeable with SKF models, ideal for replacements in industrial machinery or conveyor systems.

Weighing 2.05kg, it balances durability with manageable handling. Compliant with RoHS and REACH standards, it’s a safe choice for various applications.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 1217-TVH-C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 28 mm
  • Width Tolerance -0.2mm to 0
  • External Diameter On Inner Ring 107 mm
  • Internal Diameter On Outer Ring 131 mm
  • Chamfer Dimension 2 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 10980 lbf
  • Static Radial Load 4680 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 5600 rpm
  • Weight 2.05 kg
  • Price($) 129.82

Features

Performance Features of 1217-TVH-C3 Bearing

1217-TVH-C3 Bearing is built with chrome steel rings and balls, offering robust radial load capacity up to 10980 lbf.
Its double-row design ensures stability and smooth operation in various applications.
The nylon cage reduces friction and noise, enhancing overall performance.
With a maximum speed of 5,600 rpm, it delivers reliable efficiency.

How Does 1217-TVH-C3 Bearing Reduce Friction?

1217-TVH-C3 Bearing features a nylon cage that minimises friction during operation.
The chrome steel construction ensures durability while maintaining smooth performance.
Its double-row design helps distribute loads evenly, reducing wear.
This makes it ideal for applications requiring quiet and efficient operation.

Designed for Durability: 1217-TVH-C3 Bearing

1217-TVH-C3 Bearing’s chrome steel components provide excellent resistance to wear and tear.
The double-row construction enhances load distribution, extending service life.
It operates smoothly within a temperature range of -30° to 110°C.
This bearing is a reliable choice for demanding radial load applications.

Open vs Sealed Bearings: Benefits of 1217-TVH-C3 Bearing

1217-TVH-C3 Bearing’s open design allows for easy lubrication and maintenance.
The chrome steel rings and balls ensure long-lasting performance under radial loads.
Its nylon cage reduces noise, making it suitable for precision machinery.
With a C3 radial clearance, it accommodates thermal expansion effectively.

Application

Industrial Uses of 1217-TVH-C3 Bearing
1217-TVH-C3 Bearing is commonly used in heavy machinery like conveyor systems and industrial fans, where its self-aligning feature compensates for minor misalignments. The double-row design ensures reliable performance under radial loads, making it suitable for demanding environments.

What Makes 1217-TVH-C3 Bearing a Preferred Choice?
In automotive applications, 1217-TVH-C3 Bearing supports components like gearboxes and wheel hubs, thanks to its high dynamic radial load capacity. The nylon cage reduces friction, enhancing efficiency and longevity in high-speed scenarios.

Perfect Fit for Automation: 1217-TVH-C3 Bearing
For robotic arms and automated production lines, 1217-TVH-C3 Bearing offers smooth operation with its C3 radial clearance. The chrome steel construction ensures durability, even in continuous use.

Medical vs Industrial: Where 1217-TVH-C3 Bearing Excels
While 1217-TVH-C3 Bearing is robust enough for industrial equipment, its precision also suits medical devices like imaging systems. The lubricated design ensures quiet and reliable performance in sensitive environments.

Where to Use 1217-TVH-C3 Bearing
In household appliances like washing machines, 1217-TVH-C3 Bearing provides quiet and efficient operation. Its self-aligning capability makes it ideal for applications where shaft alignment might vary slightly.
