Self Aligning Ball Bearings 1204-TVH-C3
Self Aligning Ball Bearings 1204-TVH-C3

Self Aligning Ball Bearings 1204-TVH-C3

The 1204-TVH-C3 is a self-aligning ball bearing with a 20mm bore and 47mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 2858 lbf and operates smoothly at speeds up to 20,000 RPM.

Its double-row design and open seal allow for easy lubrication and alignment adjustments, while the nylon cage reduces friction. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. It’s well-suited for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing just 0.12kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards, it’s a safe and efficient choice for various industrial uses.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 1204-TVH-C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 47 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 14 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 28.88 mm
  • Internal Diameter On Outer Ring 40 mm
  • Chamfer Dimension 1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 2858 lbf
  • Static Radial Load 765 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 20000 rpm
  • Weight 0.12 kg
  • Price($) 19.08

Features

How Does 1204-TVH-C3 Bearing Reduce Friction?

1204-TVH-C3 Bearing features a double-row design with chrome steel balls, ensuring smooth radial load distribution.
The nylon cage minimises friction, allowing for quieter operation and reduced energy consumption.
With a maximum speed of 20,000 rpm, it maintains efficiency in high-speed applications.
Its C3 radial clearance provides optimal performance under varying thermal conditions.

Engineered for Precision: 1204-TVH-C3 Bearing

1204-TVH-C3 Bearing’s cylindrical bore design ensures easy installation and precise alignment.
The chrome steel construction offers durability, while the lubricated design reduces maintenance needs.
Its dynamic radial load capacity of 2858 lbf makes it suitable for demanding radial applications.
The open seal type allows for easy inspection and relubrication when required.

Performance Features of 1204-TVH-C3 Bearing

1204-TVH-C3 Bearing operates efficiently within a temperature range of -30° to 110°C, adapting to various environments.
The double-row ball arrangement enhances load-bearing capacity without compromising on compactness.
Its lightweight design at 0.12 kg ensures easy handling and integration into assemblies.
The C3 radial clearance accommodates thermal expansion, ensuring consistent performance.

Application

Industrial Uses of 1204-TVH-C3 Bearing
1204-TVH-C3 Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. The double-row design provides excellent radial load capacity, making it suitable for continuous operation.

In automotive applications, 1204-TVH-C3 Bearing can be found in steering columns and gearbox assemblies. Its nylon cage reduces friction, ensuring smooth performance even at higher speeds.

For automation equipment, 1204-TVH-C3 Bearing supports robotic arms and precision machinery. The C3 clearance allows for thermal expansion, maintaining reliability in varying temperatures.

Where Is 1204-TVH-C3 Bearing Used?
You’ll often spot 1204-TVH-C3 Bearing in industrial fans, where its open design helps with heat dissipation. The chrome steel construction ensures durability in dusty or humid environments.

In household appliances like washing machines, 1204-TVH-C3 Bearing handles radial loads with ease. Its lubricated design means less maintenance, which is handy for everyday use.

Built for Heavy-Duty Use: 1204-TVH-C3 Bearing
1204-TVH-C3 Bearing works well in agricultural machinery, tackling uneven loads with its self-aligning capability. The metric sizing makes it easy to replace in most European equipment.

For small electric motors, 1204-TVH-C3 Bearing offers reliable performance without needing frequent adjustments. The nylon cage also helps reduce noise, which is great for quieter operation.
