One Way Bearing HF1012-KF
One Way Bearing HF1012-KF

One Way Bearing HF1012-KF

The HF1012-KF is a compact one-way needle bearing with a 10mm bore and 14mm outer diameter, crafted from sturdy steel. It supports speeds up to 14000 RPM and handles torque up to 5.3 Nm, making it suitable for high-performance applications.
Its open design simplifies lubrication, while the steel cage and needles ensure durability. The press-fit shaft mount provides a secure installation.
This bearing operates smoothly in temperatures from -30°C to 110°C and is interchangeable with INA models. Ideal for use in small machinery or tools where one-directional rotation is needed.
Weighing just 4 grams, it’s lightweight yet robust. Compliant with RoHS standards for safe and reliable use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number HF1012-KF
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 10 mm
  • Outer Dia 14 mm
  • Width 12 mm
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Construction Single Row
  • Knurled No
  • Seal Type Open
  • Series HF Series
  • Ring Material Steel
  • Cage Material Steel
  • Needle Material Steel
  • Spring Material Plastic
  • Max Speed 14000 rpm
  • Torque Capacity 5.3 Nm
  • Lubrication Lubricated
  • Shaft Mount Type Press Fit
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • Weight 4 g

Features

Why Choose HF1012-KF Bearing for Precision Tasks?
HF1012-KF Bearing is crafted with steel rings and needles, ensuring precise operation in compact spaces.
Its press-fit shaft mount design simplifies installation, making it ideal for applications requiring accuracy.
The bearing’s torque capacity of 5.3 Nm allows it to handle demanding tasks with ease.
With a maximum speed of 14,000 rpm, it delivers reliable performance in high-speed scenarios.
HF1012-KF Bearing operates smoothly within a temperature range of -30° to 110°C.
Its open design and lubrication ensure minimal maintenance while maintaining efficiency.

Application

Common Applications of HF1012-KF Bearing
HF1012-KF Bearing is widely used in industrial machinery, especially in conveyor systems where one-way rotation is needed. Its press-fit design ensures a secure installation, reducing maintenance needs.
In automotive applications, HF1012-KF Bearing works well in gearbox mechanisms, providing smooth one-directional motion. The steel construction offers durability, even under high-speed conditions.
For automation equipment, HF1012-KF Bearing is a reliable choice for robotic arms, ensuring precise movement. Its lightweight design doesn’t compromise strength, making it ideal for repetitive tasks.
In consumer electronics, HF1012-KF Bearing can be found in printers, where its low torque helps maintain quiet operation. The lubricated design also extends its lifespan in everyday use.
