Needle Roller And Cage Assemblies K35X40X27-TV
Needle Roller And Cage Assemblies K35X40X27-TV

Needle Roller And Cage Assemblies K35X40X27-TV

The K35X40X27-TV is a needle roller and cage assembly with a 35mm bore and 40mm outer diameter, designed for metric systems. Made from durable steel needles and a PA66 cage, it offers reliable performance in compact spaces.
It handles radial loads up to 5625 lbf and spins smoothly at speeds up to 13100 RPM. The single-row construction ensures stability, while the lightweight design (just 39g) makes it easy to handle.
This assembly is interchangeable with INA bearings, simplifying replacements. Ideal for applications like gearboxes or automotive systems where space is limited but high load capacity is needed.
With a temperature range of -30°C to 110°C and RoHS compliance, it’s suitable for various industrial environments. A practical choice for engineers seeking a balance of strength and efficiency.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number K35X40X27-TV
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 35 mm
  • Outer Dia 40 mm
  • Width 27 mm
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Construction Single Row
  • Series K Series
  • Cage Material PA66
  • Needle Material Steel
  • Dynamic Radial Load 5625 lbf
  • Static Radial Load 10912 lbf
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • Max Speed 13100 rpm
  • Weight 39 g

Features

How Does K35X40X27-TV Bearing Resist Wear?
K35X40X27-TV Bearing features a PA66 cage and steel needles, ensuring durability under high radial loads.
Its dynamic radial load capacity of 5625 lbf makes it suitable for demanding applications.
The single-row construction provides stability, while the lightweight design enhances efficiency.
With a maximum speed of 13,100 rpm, it delivers reliable performance in various conditions.

Application

Key Fields for K35X40X27-TV Bearing
K35X40X27-TV Bearing is commonly used in industrial gearboxes, where its compact design and high load capacity make it ideal for space-constrained applications. The steel needles and PA66 cage ensure durability even in demanding conditions.
In automotive transmissions, K35X40X27-TV Bearing handles high radial loads smoothly, contributing to efficient power transfer. Its metric sizing allows for easy integration with various vehicle models.
For automation systems, K35X40X27-TV Bearing supports precise motion control in robotic arms and conveyor belts. The high-speed capability up to 13100 rpm ensures reliable performance in continuous operations.
Medical imaging devices benefit from K35X40X27-TV Bearing’s smooth operation and low maintenance needs. The compliant materials make it suitable for environments requiring strict hygiene standards.
Household appliances like washing machines often use K35X40X27-TV Bearing for its quiet and efficient performance. The lightweight design at just 39g helps reduce overall machine weight.
