Needle Roller And Cage Assemblies K25X29X10
Needle Roller And Cage Assemblies K25X29X10

Needle Roller And Cage Assemblies K25X29X10

The K25X29X10 is a compact needle roller and cage assembly with a 25mm bore and 29mm outer diameter, crafted from sturdy steel. It handles radial loads up to 2228 lbf and spins efficiently at speeds up to 18100 RPM.
Its single-row design with a steel cage ensures smooth operation and durability. The assembly works reliably in temperatures ranging from -30°C to 110°C.
This model is interchangeable with INA bearings, making it a practical choice for replacements. Ideal for applications like gear pumps or small engines where space is limited but performance is key.
Weighing just 8.5g, it’s lightweight yet robust for its size. Compliant with RoHS standards for safe use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number K25X29X10
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 25 mm
  • Outer Dia 29 mm
  • Width 10 mm
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Construction Single Row
  • Series K Series
  • Cage Material Steel
  • Needle Material Steel
  • Dynamic Radial Load 2228 lbf
  • Static Radial Load 3465 lbf
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • Max Speed 18100 rpm
  • Weight 8.5 g

Features

How Does K25X29X10 Bearing Achieve High-Speed Performance?
K25X29X10 Bearing features a steel cage and needles, ensuring durability and smooth operation at high speeds.
Its dynamic radial load capacity of 2228 lbf makes it suitable for demanding applications.
The compact design with a width of 10 mm allows for easy integration into tight spaces.
With a maximum speed of 18,100 rpm, it delivers reliable performance in high-speed environments.
K25X29X10 Bearing operates efficiently within a temperature range of -30° to 110°C.
Its lightweight construction at just 8.5 g reduces overall system weight without compromising strength.

Application

Common Applications of K25X29X10 Bearing
K25X29X10 Bearing is widely used in industrial gearboxes, where its compact design and high load capacity make it ideal for tight spaces. The steel construction ensures durability even in demanding conditions.
In automotive applications, K25X29X10 Bearing fits perfectly into transmission systems, providing smooth rotation under high radial loads. Its metric sizing makes it a versatile choice for various vehicle models.
For automation equipment, K25X29X10 Bearing offers reliable performance in robotic arms and conveyor systems. The high-speed capability of up to 18100 rpm ensures efficiency in fast-paced production lines.
Medical devices like surgical tools benefit from K25X29X10 Bearing’s precision and low weight. The steel needles and cage provide consistent performance in critical applications.
In household appliances, K25X29X10 Bearing can be found in electric motors and power tools. Its small size and robust design make it a practical solution for everyday use.
