Needle Roller And Cage Assemblies K24X30X17
Needle Roller And Cage Assemblies K24X30X17

Needle Roller And Cage Assemblies K24X30X17

The K24X30X17 is a compact needle roller and cage assembly with a 24mm bore and 30mm outer diameter, crafted from sturdy steel. It handles radial loads up to 4388 lbf and spins smoothly at speeds up to 18100 RPM.
Its single-row design with a steel cage ensures reliable performance in tight spaces, while the steel needles provide excellent durability. The assembly operates well in temperatures from -30°C to 110°C.
This model is interchangeable with INA bearings, making it a practical choice for replacements. Ideal for applications like transmissions or small machinery where space is limited but high load capacity is needed.
Weighing just 19g, it’s lightweight yet robust for its size. Compliant with RoHS standards for safe use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number K24X30X17
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 24 mm
  • Outer Dia 30 mm
  • Width 17 mm
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Construction Single Row
  • Series K Series
  • Cage Material Steel
  • Needle Material Steel
  • Dynamic Radial Load 4388 lbf
  • Static Radial Load 6188 lbf
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • Max Speed 18100 rpm
  • Weight 19 g

Features

How Does K24X30X17 Bearing Achieve High-Speed Performance?
K24X30X17 Bearing features a steel cage and needles, ensuring durability and smooth operation at high speeds.
With a maximum speed of 18,100 rpm, it is suitable for demanding applications requiring rapid rotation.
The dynamic radial load capacity of 4,388 lbf allows K24X30X17 Bearing to handle significant forces without compromising performance.
Its compact design, with a width of just 17 mm, makes it ideal for space-constrained installations.
K24X30X17 Bearing operates efficiently in temperatures ranging from -30° to 110°C, adapting to various environments.
The steel construction provides reliable strength, while the single-row design simplifies maintenance.

Application

Key Fields for K24X30X17 Bearing
K24X30X17 Bearing is widely used in automotive transmissions, where its compact design and high load capacity make it ideal for space-constrained applications. The steel construction ensures durability even under continuous operation.
In industrial gearboxes, K24X30X17 Bearing provides reliable performance, handling radial loads efficiently. Its high-speed capability up to 18100 rpm makes it suitable for demanding machinery.
For small electric motors, K24X30X17 Bearing offers smooth rotation and low friction. The lightweight design at just 19 grams helps maintain efficiency without adding bulk.
Where Is K24X30X17 Bearing Used?
You’ll often find K24X30X17 Bearing in motorcycle engines, where its needle roller design reduces friction and improves fuel efficiency. The metric sizing ensures easy integration with various models.
In power tools, K24X30X17 Bearing handles high rotational speeds while maintaining stability. Its steel cage and needles provide long-lasting performance even in tough conditions.
Built for Heavy-Duty Use: K24X30X17 Bearing
K24X30X17 Bearing excels in construction equipment, where its ability to handle heavy radial loads keeps machinery running smoothly. The temperature range from -30° to 110°C ensures reliability in diverse environments.
For agricultural machinery, K24X30X17 Bearing’s robust design withstands dust and debris. Its compatibility with INA bearings makes replacements straightforward.
Automotive vs Aerospace: Applications of K24X30X17 Bearing
In automotive systems, K24X30X17 Bearing is commonly used in steering mechanisms, offering precise control and durability. The high static radial load capacity of 6188 lbf ensures safety.
For aerospace applications, K24X30X17 Bearing’s lightweight and high-speed performance make it suitable for auxiliary systems. Its RoHS compliance meets strict industry standards.
