The SF692 is a compact radial ball bearing with a 2mm bore and 6mm outer diameter, crafted entirely from stainless steel for durability. It handles radial loads up to 57 lbf and spins at impressive speeds up to 67,500 RPM.
Its open design simplifies lubrication, while the stainless steel cage ensures smooth operation. The bearing includes a small flange (7.5mm outer diameter) for secure mounting in tight spaces.
With a radial clearance of 0.002mm to 0.013mm, it offers precise movement for delicate applications. Ideal for small devices like precision instruments or miniature motors where space is limited.
Weighing just 0.35g, it’s lightweight yet robust. Compliant with RoHS and REACH standards, it operates in temperatures from -30°C to 110°C.
"*" indicates required fields
Performance Features of SF692 Bearing
SF692 Bearing is crafted with stainless steel rings and balls, offering reliable radial load support.
Its dynamic radial load capacity of 57 lbf ensures steady performance in high-speed applications.
The open design allows for easy lubrication, maintaining smooth operation over time.
With a maximum speed of 67,500 rpm, SF692 Bearing excels in precision tasks.
The stainless steel cage ensures proper ball alignment, reducing friction and wear.
Its compact size and lightweight design make it ideal for small-scale machinery.
SF692 Bearing operates efficiently in temperatures ranging from -30° to 110°C.
The ABEC1 tolerance class guarantees consistent performance for standard applications.
Its radial clearance of 0.002mm to 0.013mm ensures smooth rotation under load.
Where Is SF692 Bearing Used?
SF692 Bearing is commonly used in small precision instruments, such as dental drills and watch mechanisms, where its compact size and high-speed capability are essential. The stainless steel construction ensures durability in these delicate applications.
In robotics, SF692 Bearing supports lightweight joints and miniature actuators, providing smooth movement with minimal friction. Its open design allows for easy lubrication, extending the bearing’s lifespan in continuous operation.
For consumer electronics like miniature fans or small motors, SF692 Bearing offers reliable performance due to its high RPM tolerance. The metric dimensions make it a versatile choice for various compact devices.
The ABEC1 tolerance class ensures consistent performance in applications like laboratory equipment, where precision is key. Its lightweight design also makes it suitable for portable devices requiring minimal energy consumption.
