Metric Single Direction Thrust Ball Bearing 53218
Metric Single Direction Thrust Ball Bearing 53218

Metric Single Direction Thrust Ball Bearing 53218

The 53218 is a single-direction thrust ball bearing with a 90mm bore and 135mm outer diameter, crafted from tough 52100 chrome steel. It manages thrust loads up to 25200 lbf and operates smoothly at speeds up to 2600 RPM.

Its open design simplifies maintenance, while the stainless steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a dependable replacement option. Suitable for heavy-duty applications like industrial presses or large gear systems where high thrust loads are expected.

Weighing 2.1kg, it’s sturdy yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 53218
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Thrust
  • Seal Type Open
  • Bore Dia 90 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 135 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Outer Dia Shaft Washer 135 mm
  • Width 38.5 mm
  • Width Tolerance +0.025mm to -0.3mm
  • Inner Dia Housing Washer 93 mm
  • Chamfer Dimension 1.1 mm
  • Ring Material 52100 Chrome Steel
  • Ball Material 52100 Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Thrust Load 25200 lbf
  • Static Thrust Load 65250 lbf
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 2600 rpm
  • Weight 2.1 kg

Features

Performance Features of 53218 Bearing

53218 Bearing is built with 52100 chrome steel rings and balls, offering strong resistance to high thrust loads.
Its dynamic thrust load capacity reaches 25200 lbf, making it suitable for heavy-duty applications.

The stainless steel cage ensures proper ball alignment, reducing friction and wear.
With a maximum speed of 2,600 rpm, it delivers reliable performance under demanding conditions.

53218 Bearing operates efficiently in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication, ensuring smooth operation over time.

The precise tolerances of 53218 Bearing contribute to its long service life.
Its robust construction makes it a dependable choice for industrial applications.

Application

Common Applications of 53218 Bearing
53218 Bearing is widely used in industrial settings, especially in heavy machinery like hydraulic presses and large conveyor systems. Its robust design handles high thrust loads efficiently, making it reliable for continuous operation.

In the automotive sector, 53218 Bearing fits well in gearboxes and drivetrain components, where its chrome steel construction ensures longevity. The open seal design simplifies lubrication and maintenance, which is handy for fleet vehicles.

For automation systems, 53218 Bearing supports robotic arms and assembly line equipment, providing smooth movement under axial loads. The stainless steel cage adds durability, even in high-cycle applications.

Medical imaging devices also benefit from 53218 Bearing’s precision and stability. Its consistent performance is crucial for accurate diagnostics, while the temperature range suits clinical environments.

Around the home, 53218 Bearing can be found in heavy-duty appliances like washing machines. Its load capacity and wear resistance make it a practical choice for daily use.
