Heavy Duty Needle Roller Bearings (Machined) NK10/12-TV-XL
Heavy Duty Needle Roller Bearings (Machined) NK10/12-TV-XL

Heavy Duty Needle Roller Bearings (Machined) NK10/12-TV-XL

The NK10/12-TV-XL is a heavy-duty needle roller bearing with a 10mm bore and 17mm outer diameter, crafted from sturdy steel for reliable performance. It handles radial loads up to 1192 lbf and spins at speeds up to 29,500 RPM, making it suitable for high-speed applications.
Its open design and PA66 cage ensure smooth operation, while the press-fit shaft mount provides a secure installation. The bearing requires regular lubrication to maintain optimal performance.
This model works well in temperatures from -20°C to 110°C and is interchangeable with INA bearings, offering flexibility for replacements. Ideal for use in compact machinery or automotive components where space is limited.
Weighing just 10.1g, it’s lightweight yet durable. Compliant with RoHS standards for safe and eco-friendly use.

Get A Free Quote

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number NK10/12-TV-XL
  • Brand TFL
  • Interchangeable brand INA
  • System of Measurement Metric
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Inner Ring No
  • Series Without Inner Ring
  • Bore Dia 10 mm
  • Bore Dia Tolerance 0.013mm to 0.022mm
  • Outer Dia 17 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 12 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Steel
  • Cage Material PA66
  • Roller Material Steel
  • Dynamic Radial Load 1192 lbf
  • Static Radial Load 1238 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 29500 rpm
  • Weight 10.1 g

Features

How Does NK10/12-TV-XL Bearing Handle High-Speed Applications?
NK10/12-TV-XL Bearing is designed with steel rollers and a PA66 cage, ensuring smooth operation at high speeds.
Its dynamic radial load capacity of 1192 lbf makes it suitable for demanding radial load applications.
The press-fit shaft mount type ensures secure installation, reducing the risk of slippage during operation.
With a maximum speed of 29,500 rpm, it delivers reliable performance in high-speed environments.

Application

Industrial Uses of NK10/12-TV-XL Bearing
NK10/12-TV-XL Bearing is commonly used in industrial machinery, especially in compact spaces where high radial load capacity is needed, such as conveyor systems and textile machines. Its open design and press-fit mounting make it easy to install and maintain.
Where Is NK10/12-TV-XL Bearing Used?
In automotive applications, NK10/12-TV-XL Bearing fits well in gearboxes and steering systems, thanks to its high-speed capability and steel construction. The needle roller design ensures efficient load distribution even in tight spaces.
Built for Heavy-Duty Use: NK10/12-TV-XL Bearing
For automation equipment like robotic arms, NK10/12-TV-XL Bearing offers reliable performance due to its PA66 cage and steel rollers. Its lightweight design also helps reduce overall system weight.
Automotive vs Industrial: Applications of NK10/12-TV-XL Bearing
In consumer electronics, NK10/12-TV-XL Bearing can be found in printers and small appliances, where its compact size and durability are key. The metric dimensions ensure compatibility with a variety of devices.
