The FAG NUP217-E-XL-TVP2-F1-J20AA-C3 is a current-insulated cylindrical roller bearing with dimensions of 85mm bore, 150mm outer diameter, and 28mm width. Made with a ceramic-coated outer ring, it prevents electrical currents from damaging the bearing.
This model handles dynamic and static loads up to 194kN, with a reference speed of 4000 RPM. Its plastic cage ensures smooth operation and reduces friction during high-speed use.
The insulating coating offers a breakdown voltage of up to 1000V, making it ideal for electric motors or generators. It’s also compliant with RoHS and REACH standards for environmental safety.
Weighing 1.89kg, it’s a durable choice for industrial applications where electrical insulation is needed. Suitable for machinery exposed to stray currents or damp conditions.
"*" indicates required fields
How Is NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing Engineered for Reliability?
NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing features an outer ring ceramic coating, providing excellent electrical insulation.
This design prevents current passage, reducing the risk of damage in electrically active environments.
The plastic molded cage ensures smooth operation and reduces friction during high-speed rotation.
With a basic dynamic load rating of 194 kN, it handles heavy loads efficiently.
NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing operates reliably at speeds up to 4000r/min, maintaining performance under stress.
Its C3 radial internal clearance allows for thermal expansion in demanding applications.
The coating offers high electrical resistance, with 50MΩ when dry and 10MΩ in damp conditions.
This makes NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing suitable for varied operational environments.
Industrial Uses of NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing
NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing is commonly used in electric motors and generators, where its current-insulating coating prevents electrical arcing. The ceramic outer ring coating ensures reliable performance in environments with stray currents.
In heavy machinery like rolling mills, NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing handles high radial loads with ease. Its plastic cage reduces friction, making it suitable for high-speed operations.
For wind turbine applications, NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing’s C3 clearance accommodates thermal expansion. The breakdown voltage rating up to 1000V adds an extra layer of safety in variable conditions.
What Makes NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing a Preferred Choice?
NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing is ideal for conveyor systems in mining, where dust and moisture resistance are crucial. The damp electrical resistance of 10MΩ ensures consistent performance even in humid environments.
In railway applications, NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing’s robust design withstands heavy loads and vibrations. The plastic cage material helps dampen noise, enhancing passenger comfort.
Built for Heavy-Duty Use: NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing
NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing excels in steel production equipment, handling extreme temperatures and loads. Its ceramic coating prevents electrical damage, extending service life.
For paper manufacturing machinery, NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing offers reliable performance in wet conditions. The C3 clearance allows for smooth operation despite thermal fluctuations.
Automotive vs Aerospace: Applications of NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing
In automotive alternators, NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing prevents electrical current leakage, ensuring efficient power generation. The high dynamic load rating suits demanding engine environments.
For aerospace ground equipment, NUP217-E-XL-TVP2-F1-J20AA-C3 Bearing’s lightweight design and insulation properties are advantageous. The plastic cage reduces weight without compromising durability.
