The FAG NUP215-E-M1-F1-J20AA-C3-M32AX is a current-insulated cylindrical roller bearing with a 75mm bore and 130mm outer diameter, designed to prevent electrical damage. Its outer ring features a ceramic coating (J20AA) for insulation, with a breakdown voltage of up to 1000V.
This bearing handles dynamic loads up to 155 kN and static loads up to 157 kN, making it suitable for high-demand applications. It operates smoothly at speeds up to 4400 RPM and has a C3 radial clearance for better thermal expansion handling.
The brass cage ensures durability, while the 200-micron coating provides reliable insulation even in damp conditions (10MΩ resistance). It’s ROHS and REACH compliant for safe use.
Ideal for electric motors or generators where current leakage is a concern, this bearing offers both mechanical strength and electrical protection. Weighing 1.47kg, it balances performance and practicality.
"*" indicates required fields
How Is NUP215-E-M1-F1-J20AA-C3-M32AX Bearing Engineered for Reliability?
NUP215-E-M1-F1-J20AA-C3-M32AX Bearing features an outer ring ceramic coating, providing excellent electrical insulation.
This design prevents current passage, reducing the risk of damage in electrically active environments.
The brass cage ensures smooth operation and durability under high dynamic loads.
With a basic dynamic load rating of 155 kN, it handles heavy-duty applications efficiently.
NUP215-E-M1-F1-J20AA-C3-M32AX Bearing’s C3 radial internal clearance allows for thermal expansion in demanding conditions.
Its reference speed of 4400r/min ensures reliable performance in high-speed applications.
The coating offers a breakdown voltage of ≤1000v, making it suitable for various industrial uses.
This bearing is designed to maintain performance even in damp conditions, with an electrical resistance of 10MΩ.
Industrial Uses of NUP215-E-M1-F1-J20AA-C3-M32AX Bearing
NUP215-E-M1-F1-J20AA-C3-M32AX Bearing is commonly used in electric motors and generators, where its current-insulating coating prevents electrical arcing. The brass cage ensures smooth operation even under high radial loads.
In automation systems, NUP215-E-M1-F1-J20AA-C3-M32AX Bearing supports robotic arms and conveyor belts, thanks to its C3 clearance for thermal expansion. The ceramic coating adds durability in dusty or humid environments.
For wind turbines, NUP215-E-M1-F1-J20AA-C3-M32AX Bearing handles variable loads while maintaining electrical insulation. Its high dynamic load rating makes it reliable for continuous operation.
What Makes NUP215-E-M1-F1-J20AA-C3-M32AX Bearing a Preferred Choice?
NUP215-E-M1-F1-J20AA-C3-M32AX Bearing is ideal for CNC machines, where precision and insulation are key. The ceramic outer ring coating reduces downtime from electrical damage.
In railway applications, NUP215-E-M1-F1-J20AA-C3-M32AX Bearing ensures stable performance in traction motors. Its brass cage withstands vibrations and heavy loads common in rail transport.
For industrial pumps, NUP215-E-M1-F1-J20AA-C3-M32AX Bearing offers reliable sealing against contaminants. The C3 clearance accommodates thermal changes during prolonged use.
Built for Heavy-Duty Use: NUP215-E-M1-F1-J20AA-C3-M32AX Bearing
NUP215-E-M1-F1-J20AA-C3-M32AX Bearing excels in steel mills, where high temperatures and heavy loads are common. The ceramic coating prevents current leakage in critical machinery.
In mining equipment, NUP215-E-M1-F1-J20AA-C3-M32AX Bearing provides robust support for crushers and conveyors. Its brass cage enhances durability in abrasive environments.
For marine applications, NUP215-E-M1-F1-J20AA-C3-M32AX Bearing resists corrosion from saltwater exposure. The insulating properties are crucial for onboard electrical systems.
