The FAG NU324-E-XL-M1-F1-J20AA-C4-M30AX is a current-insulated cylindrical roller bearing with dimensions of 120mm bore, 260mm outer diameter, and 55mm width. It features a ceramic coating on the outer ring for electrical insulation, preventing current damage in machinery.
With a dynamic load rating of 610 kN and static load rating of 600 kN, it handles heavy radial loads efficiently. The brass cage ensures smooth operation at speeds up to 2650 RPM, even in demanding conditions.
The C4 radial clearance allows for thermal expansion, making it suitable for high-temperature applications. Its insulation properties include a breakdown voltage of up to 1000V and resistance of 50MΩ when dry.
Ideal for electric motors, generators, or any equipment where electrical currents could cause bearing damage. Compliant with ROHS and REACH standards, it’s a reliable choice for industrial applications. Weighing 14.4kg, it balances durability with manageable handling.
"*" indicates required fields
How Does NU324-E-XL-M1-F1-J20AA-C4-M30AX Bearing Resist Electrical Current?
NU324-E-XL-M1-F1-J20AA-C4-M30AX Bearing features an outer ring ceramic coating, providing excellent insulation against electrical currents.
The coating offers a breakdown voltage of up to 1000v, making it suitable for applications with electrical interference.
Its brass cage ensures smooth operation and reduces friction, even under high dynamic loads of 610 kN.
The bearing maintains reliable performance in damp conditions, with an electrical resistance of 10MΩ.
With a reference speed of 2650r/min, NU324-E-XL-M1-F1-J20AA-C4-M30AX Bearing balances speed and durability.
The C4 radial internal clearance allows for thermal expansion, ensuring stability in varying temperatures.
Industrial Uses of NU324-E-XL-M1-F1-J20AA-C4-M30AX Bearing
NU324-E-XL-M1-F1-J20AA-C4-M30AX Bearing is commonly used in electric motors and generators, where its current-insulating coating prevents electrical arcing. The brass cage ensures smooth operation even under high rotational speeds.
What Makes NU324-E-XL-M1-F1-J20AA-C4-M30AX Bearing a Preferred Choice?
In wind turbines, NU324-E-XL-M1-F1-J20AA-C4-M30AX Bearing handles heavy radial loads while its ceramic coating protects against stray currents. Its C4 clearance allows for thermal expansion in demanding environments.
Built for Heavy-Duty Use: NU324-E-XL-M1-F1-J20AA-C4-M30AX Bearing
NU324-E-XL-M1-F1-J20AA-C4-M30AX Bearing excels in industrial gearboxes, where its high dynamic load rating ensures long service life. The damp-resistant design maintains performance even in humid conditions.
Automotive vs Aerospace: Applications of NU324-E-XL-M1-F1-J20AA-C4-M30AX Bearing
In automotive drivetrains, NU324-E-XL-M1-F1-J20AA-C4-M30AX Bearing supports shafts with precision, while its aerospace applications benefit from the insulating properties. The consistent performance makes it versatile across industries.
Perfect Fit for Automation: NU324-E-XL-M1-F1-J20AA-C4-M30AX Bearing
NU324-E-XL-M1-F1-J20AA-C4-M30AX Bearing is ideal for robotic arms in automated production lines, where its high-speed capability and electrical insulation are crucial. The brass cage reduces friction for smoother movements.
