The FAG NU314-E-XL-M1-F1-J20B-C4 is a current-insulated cylindrical roller bearing, sized at 70mm bore and 150mm outer diameter, with a width of 35mm. Its outer ring features a ceramic coating for electrical insulation, preventing damage from stray currents.
With a dynamic load rating of 242 kN and a static load rating of 222 kN, it handles heavy radial loads efficiently. The brass cage ensures smooth operation at speeds up to 4500 rpm, even in demanding conditions.
The ceramic coating provides a breakdown voltage of up to 500V and maintains high electrical resistance. This makes it ideal for electric motors or generators where electrical insulation is crucial.
Weighing 3.08 kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a reliable choice for industrial applications requiring both mechanical and electrical performance.
"*" indicates required fields
How Is NU314-E-XL-M1-F1-J20B-C4 Bearing Engineered for Reliability?
NU314-E-XL-M1-F1-J20B-C4 Bearing features an outer ring ceramic coating, providing excellent electrical insulation.
This design prevents current passage, reducing the risk of damage in electrically active environments.
The brass cage ensures smooth operation and enhances durability under high loads.
With a basic dynamic load rating of 242 kN, it handles demanding applications with ease.
NU314-E-XL-M1-F1-J20B-C4 Bearing’s C4 radial internal clearance allows for thermal expansion in high-speed operations.
Its reference speed of 4500r/min makes it suitable for various industrial uses.
The ceramic coating offers high electrical resistance, even in damp conditions.
This ensures reliable performance in challenging environments.
Industrial Uses of NU314-E-XL-M1-F1-J20B-C4 Bearing
NU314-E-XL-M1-F1-J20B-C4 Bearing is commonly used in electric motors and generators, where its current-insulating properties prevent electrical damage. The brass cage ensures smooth operation even under high rotational speeds.
In wind turbines, NU314-E-XL-M1-F1-J20B-C4 Bearing handles radial loads efficiently while resisting electrical arcing. Its ceramic-coated outer ring adds an extra layer of protection in harsh environments.
For railway applications, NU314-E-XL-M1-F1-J20B-C4 Bearing’s robust design supports heavy loads in traction motors. The C4 clearance allows for thermal expansion during prolonged use.
What Makes NU314-E-XL-M1-F1-J20B-C4 Bearing a Preferred Choice?
NU314-E-XL-M1-F1-J20B-C4 Bearing is ideal for industrial gearboxes, offering reliable performance under varying loads. Its high dynamic load rating makes it suitable for continuous operation.
In mining equipment, NU314-E-XL-M1-F1-J20B-C4 Bearing’s durability reduces downtime in conveyor systems. The insulating coating prevents current-induced wear, extending service life.
For pump systems, NU314-E-XL-M1-F1-J20B-C4 Bearing’s resistance to damp conditions ensures consistent performance. The brass cage maintains stability even in corrosive environments.
Built for Heavy-Duty Use: NU314-E-XL-M1-F1-J20B-C4 Bearing
NU314-E-XL-M1-F1-J20B-C4 Bearing excels in steel mill applications, where high temperatures and heavy loads are common. Its ceramic coating provides insulation against stray currents.
In paper manufacturing machinery, NU314-E-XL-M1-F1-J20B-C4 Bearing’s high-speed capability keeps production lines running smoothly. The C4 clearance accommodates thermal expansion.
For marine propulsion systems, NU314-E-XL-M1-F1-J20B-C4 Bearing’s damp-resistant design ensures reliability in challenging conditions. The brass cage adds durability against saltwater exposure.
Automotive vs Aerospace: Applications of NU314-E-XL-M1-F1-J20B-C4 Bearing
In automotive electric power steering systems, NU314-E-XL-M1-F1-J20B-C4 Bearing provides smooth operation with its current-insulating feature. The high load rating supports frequent directional changes.
For aerospace actuators, NU314-E-XL-M1-F1-J20B-C4 Bearing’s lightweight design and insulation properties are crucial. Its reliability ensures precise control in critical systems.
In hybrid vehicle drivetrains, NU314-E-XL-M1-F1-J20B-C4 Bearing handles both radial and electrical challenges. The brass cage enhances performance under continuous use.
