The NU314-E-M1-F1-J20B-C4 is a current-insulated cylindrical roller bearing with a 70mm bore and 150mm outer diameter, crafted for durability. Its outer ring features a ceramic coating to prevent electrical damage, making it ideal for electric motors.
With a dynamic load rating of 242 kN and a static load rating of 222 kN, it handles heavy radial loads smoothly. The brass cage ensures stability at speeds up to 4500 RPM, even in demanding conditions.
The ceramic coating provides insulation with a breakdown voltage of up to 500V, protecting against electrical currents. Its C4 radial clearance allows for thermal expansion in high-temperature environments.
Suitable for use in generators or industrial machinery, this bearing is RoHS and REACH compliant. Weighing 3.08kg, it balances strength and practicality for long-term performance.
"*" indicates required fields
Performance Features of NU314-E-M1-F1-J20B-C4 FAG Bearing
NU314-E-M1-F1-J20B-C4 FAG Bearing features an outer ring ceramic coating, providing excellent electrical insulation.
This design prevents current passage, reducing the risk of damage in electrically active environments.
The brass cage ensures smooth operation and durability, even under high dynamic loads up to 242 kN.
Its C4 radial internal clearance allows for thermal expansion in demanding applications.
With a breakdown voltage of ≤500V, NU314-E-M1-F1-J20B-C4 FAG Bearing is ideal for electric motors and generators.
The coating maintains high electrical resistance, even in damp conditions.
NU314-E-M1-F1-J20B-C4 FAG Bearing’s reference speed of 4500r/min ensures reliable performance in high-speed applications.
Its robust construction and insulation properties make it a practical choice for various industrial uses.
Industrial Uses of NU314-E-M1-F1-J20B-C4 FAG Bearing
NU314-E-M1-F1-J20B-C4 FAG Bearing is commonly used in electric motors and generators, where its current-insulating coating prevents electrical arcing. The brass cage ensures smooth operation even under high radial loads.
In wind turbines, NU314-E-M1-F1-J20B-C4 FAG Bearing handles variable loads efficiently, thanks to its C4 clearance. The ceramic-coated outer ring adds durability in harsh weather conditions.
For industrial pumps, NU314-E-M1-F1-J20B-C4 FAG Bearing’s high dynamic load rating makes it reliable for continuous operation. Its damp-resistant design also suits environments with moisture exposure.
Where Is NU314-E-M1-F1-J20B-C4 FAG Bearing Used?
NU314-E-M1-F1-J20B-C4 FAG Bearing fits well in conveyor systems, where its insulation properties reduce downtime from electrical damage. The 35mm width provides stability for heavy material handling.
In railway applications, NU314-E-M1-F1-J20B-C4 FAG Bearing supports axle boxes with its robust construction. The 150mm outer diameter offers ample surface area for load distribution.
Built for Heavy-Duty Use: NU314-E-M1-F1-J20B-C4 FAG Bearing
NU314-E-M1-F1-J20B-C4 FAG Bearing excels in steel mills, where high temperatures and heavy loads are common. Its 242 kN dynamic rating ensures long service life.
The bearing’s 4500r/min reference speed makes it suitable for high-speed machinery. Dry electrical resistance of 50MΩ prevents current leakage effectively.
Automotive vs Aerospace: Applications of NU314-E-M1-F1-J20B-C4 FAG Bearing
In automotive drivetrains, NU314-E-M1-F1-J20B-C4 FAG Bearing handles thrust loads with its cylindrical roller design. The 70mm bore fits standard shaft sizes.
For aerospace components, the bearing’s ceramic coating resists electrical interference. Its 3.08kg weight balances strength and portability for aircraft systems.
