The FAG NU226-E-XL-M1-J20AA-C3 is a current-insulated cylindrical roller bearing with dimensions of 130mm bore, 230mm outer diameter, and 40mm width. Its outer ring features a ceramic coating for electrical insulation, preventing damage from stray currents.
This bearing handles dynamic loads up to 425 kN and static loads up to 445 kN, with a reference speed of 2800 RPM. The brass cage ensures smooth operation and durability under heavy loads.
Its special J20AA coating provides high electrical resistance (50MΩ when dry), making it ideal for electric motors or generators. The C3 radial clearance allows for thermal expansion in demanding conditions.
Weighing 7.95kg, it’s a robust choice for industrial applications where electrical insulation is needed. Compliant with RoHS and REACH standards for safe use in various environments.
"*" indicates required fields
How Does NU226-E-XL-M1-J20AA-C3 Bearing Resist Electrical Current?
NU226-E-XL-M1-J20AA-C3 Bearing features a ceramic-coated outer ring, providing effective insulation against electrical currents.
This design prevents damage from stray currents, ensuring reliable operation in electrically charged environments.
The brass cage maintains proper roller alignment, reducing friction and wear during high-speed rotation.
With a reference speed of 2800r/min, it balances performance and durability in demanding applications.
Its basic dynamic load rating of 425 kN allows it to handle heavy radial loads with ease.
The C3 radial internal clearance ensures optimal performance under varying thermal conditions.
The coating offers high electrical resistance, measuring 50MΩ when dry and 10MΩ in damp conditions.
This makes NU226-E-XL-M1-J20AA-C3 Bearing suitable for use in diverse industrial environments.
Industrial Uses of NU226-E-XL-M1-J20AA-C3 Bearing
NU226-E-XL-M1-J20AA-C3 Bearing is commonly used in industrial motors and generators, where its current-insulating coating prevents electrical damage. The brass cage ensures smooth operation even under high radial loads.
What Makes NU226-E-XL-M1-J20AA-C3 Bearing a Preferred Choice?
In wind turbines, NU226-E-XL-M1-J20AA-C3 Bearing handles high dynamic loads while its ceramic coating protects against stray currents. Its C3 clearance allows for thermal expansion in demanding environments.
Built for Heavy-Duty Use: NU226-E-XL-M1-J20AA-C3 Bearing
NU226-E-XL-M1-J20AA-C3 Bearing excels in rolling mills, where its robust design withstands continuous heavy loads. The 425 kN dynamic load rating makes it reliable for long-term use.
Automotive vs Aerospace: Applications of NU226-E-XL-M1-J20AA-C3 Bearing
In automotive drivetrains, NU226-E-XL-M1-J20AA-C3 Bearing supports high-speed shafts with minimal maintenance. For aerospace applications, its insulation properties prevent electrical arcing in critical systems.
Perfect Fit for Automation: NU226-E-XL-M1-J20AA-C3 Bearing
NU226-E-XL-M1-J20AA-C3 Bearing is ideal for robotic arms in automated production lines. The 2800r/min reference speed ensures precise movement without overheating.
