The FAG NU224-E-TVP2-J20AA-C3 is a current-insulated cylindrical roller bearing with dimensions of 120mm bore, 215mm outer diameter, and 40mm width. Its outer ring features a ceramic coating to prevent electrical currents, making it ideal for electric motors.
With a dynamic load rating of 390 kN and a static load rating of 415 kN, it handles heavy radial loads efficiently. The plastic cage ensures smooth operation at speeds up to 3050 RPM.
The ceramic coating provides insulation with a breakdown voltage of up to 1000V, suitable for damp or dry conditions. Its C3 radial clearance allows for thermal expansion in demanding environments.
This bearing is perfect for industrial applications like generators or wind turbines where electrical insulation is crucial. Compliant with RoHS and REACH standards, it’s both durable and environmentally friendly. Weighing 5.8kg, it balances strength and practicality.
"*" indicates required fields
How Does NU224-E-TVP2-J20AA-C3 Bearing Resist Electrical Current?
NU224-E-TVP2-J20AA-C3 Bearing features an outer ring ceramic coating, providing excellent insulation against electrical currents.
Its breakdown voltage reaches up to 1000V, making it suitable for applications where electrical isolation is crucial.
The plastic molded cage ensures smooth operation while reducing friction and wear.
With a dynamic load rating of 390 kN, it delivers reliable performance under heavy loads.
What Makes NU224-E-TVP2-J20AA-C3 Bearing Suitable for High-Speed Applications?
NU224-E-TVP2-J20AA-C3 Bearing is designed for high-speed operations, with a reference speed of 3050r/min.
The ceramic-coated outer ring not only insulates but also enhances durability in demanding conditions.
Its C3 radial internal clearance allows for thermal expansion, ensuring consistent performance.
The plastic cage reduces weight and noise, making it ideal for precision machinery.
Engineered for Precision: NU224-E-TVP2-J20AA-C3 Bearing
NU224-E-TVP2-J20AA-C3 Bearing offers precise operation with its cylindrical roller design and plastic cage.
The ceramic coating ensures electrical resistance, even in damp conditions, with 10MΩ resistance.
Its static load rating of 415 kN provides stability under heavy loads.
The bearing’s dimensions (120x215x40 mm) make it versatile for various industrial applications.
Steel vs Ceramic Bearings: Strengths of NU224-E-TVP2-J20AA-C3 Bearing
NU224-E-TVP2-J20AA-C3 Bearing combines the strength of steel with the insulation of ceramic coating.
The outer ring’s 200 um ceramic layer prevents electrical arcing, extending the bearing’s life.
Its plastic cage minimises friction, ensuring smooth and quiet operation.
With a net weight of 5.8 kg, it balances durability and ease of handling.
Industrial Uses of NU224-E-TVP2-J20AA-C3 Bearing
NU224-E-TVP2-J20AA-C3 Bearing is commonly used in electric motors and generators, where its current-insulating coating prevents electrical arcing. The ceramic outer ring coating ensures reliable performance in environments with stray currents.
In wind turbine applications, NU224-E-TVP2-J20AA-C3 Bearing handles high radial loads while maintaining electrical insulation. Its C3 clearance allows for thermal expansion, making it suitable for variable operating conditions.
For industrial pumps, NU224-E-TVP2-J20AA-C3 Bearing’s plastic cage reduces friction and wear, extending service life. The high dynamic load rating ensures durability even in continuous operation scenarios.
What Makes NU224-E-TVP2-J20AA-C3 Bearing a Preferred Choice?
NU224-E-TVP2-J20AA-C3 Bearing is ideal for conveyor systems in mining, where its insulation protects against electrical damage. The robust design also copes well with heavy loads and harsh environments.
In railway applications, NU224-E-TVP2-J20AA-C3 Bearing’s breakdown voltage rating ensures safety in electrified tracks. The cylindrical roller design provides smooth rotation under varying load conditions.
Built for Heavy-Duty Use: NU224-E-TVP2-J20AA-C3 Bearing
NU224-E-TVP2-J20AA-C3 Bearing excels in steel mill equipment, where high temperatures and loads are common. The ceramic coating maintains insulation even in demanding conditions.
For paper manufacturing machinery, NU224-E-TVP2-J20AA-C3 Bearing’s damp resistance ensures reliable performance. Its static load rating guarantees stability during start-up and shutdown phases.
