The FAG NU220-E-TVP2-J20AA-C3 is a current-insulated cylindrical roller bearing with a 100mm bore and 180mm outer diameter, designed to handle heavy radial loads up to 295 kN. Its ceramic-coated outer ring provides electrical insulation, preventing damage from stray currents.
This bearing features a plastic cage for smooth operation at speeds up to 3450 rpm, even in damp conditions. The C3 radial clearance allows for thermal expansion, making it suitable for variable temperature environments.
The insulation can withstand up to 1000V, with a dry resistance of 50MΩ. Ideal for electric motors or generators where electrical currents might cause issues. Compliant with RoHS and REACH standards, it weighs 3.49kg for easy handling.
"*" indicates required fields
How Is NU220-E-TVP2-J20AA-C3 Bearing Engineered for Reliability?
NU220-E-TVP2-J20AA-C3 Bearing features an outer ring ceramic coating, providing excellent current insulation.
This design prevents electrical damage, ensuring reliable performance in electrically charged environments.
The plastic molded cage maintains smooth operation, reducing friction and wear.
With a basic dynamic load rating of 295 kN, it handles heavy loads efficiently.
NU220-E-TVP2-J20AA-C3 Bearing operates at speeds up to 3450r/min, balancing speed and durability.
Its C3 radial internal clearance allows for thermal expansion in demanding conditions.
The coating offers high electrical resistance, with 50MΩ when dry and 10MΩ when damp.
This makes NU220-E-TVP2-J20AA-C3 Bearing suitable for various industrial applications.
Industrial Uses of NU220-E-TVP2-J20AA-C3 Bearing
NU220-E-TVP2-J20AA-C3 Bearing is commonly used in industrial motors and generators, where its current-insulating coating prevents electrical arcing. The ceramic outer ring coating ensures reliable performance in electrically charged environments.
In wind turbine applications, NU220-E-TVP2-J20AA-C3 Bearing handles high radial loads while maintaining insulation properties. Its plastic cage reduces friction, making it suitable for continuous operation.
For railway traction motors, NU220-E-TVP2-J20AA-C3 Bearing offers durability and electrical insulation. The C3 clearance allows for thermal expansion, ensuring stable performance under varying temperatures.
Where Is NU220-E-TVP2-J20AA-C3 Bearing Used?
NU220-E-TVP2-J20AA-C3 Bearing is ideal for electric vehicle drivetrains, where insulation is crucial to prevent current leakage. Its high dynamic load rating supports efficient power transmission.
In industrial pumps, NU220-E-TVP2-J20AA-C3 Bearing provides reliable operation with minimal maintenance. The ceramic coating resists wear, even in damp conditions.
Built for Heavy-Duty Use: NU220-E-TVP2-J20AA-C3 Bearing
NU220-E-TVP2-J20AA-C3 Bearing excels in steel mill equipment, handling heavy loads and high temperatures. The plastic cage ensures smooth rotation under stress.
For mining machinery, NU220-E-TVP2-J20AA-C3 Bearing’s robust design withstands harsh conditions. Its electrical insulation properties add an extra layer of safety.
Automotive vs Aerospace: Applications of NU220-E-TVP2-J20AA-C3 Bearing
In automotive electric motors, NU220-E-TVP2-J20AA-C3 Bearing prevents electrical damage, ensuring long service life. The metric dimensions make it compatible with various designs.
For aerospace ground equipment, NU220-E-TVP2-J20AA-C3 Bearing offers precision and reliability. The ceramic coating provides additional protection against electrical interference.
