The FAG NU213-E-XL-M1-H257A-J20B-C4 is a current-insulated cylindrical roller bearing with a 65mm bore and 120mm outer diameter, designed to handle electrical currents. Its outer ring features a ceramic coating (J20B) for insulation, preventing damage from stray currents.
With a dynamic load rating of 128 kN and static load rating of 120 kN, it supports heavy radial loads while spinning smoothly at speeds up to 4900 RPM. The brass cage ensures durability and stable operation.
The C4 radial clearance allows for thermal expansion, making it suitable for high-temperature environments. It complies with RoHS and REACH standards, weighing just 1.17kg for easy handling.
Ideal for electric motors, generators, or any machinery where electrical insulation is needed. The coating resists voltages up to 500V and maintains high resistance even in damp conditions.
"*" indicates required fields
How Does NU213-E-XL-M1-H257A-J20B-C4 Bearing Prevent Electrical Damage?
NU213-E-XL-M1-H257A-J20B-C4 Bearing features an outer ring ceramic coating, providing excellent insulation against electrical currents.
The coating ensures a breakdown voltage of up to 500V, protecting against electrical damage in demanding environments.
With a brass cage, NU213-E-XL-M1-H257A-J20B-C4 Bearing maintains stability and reduces wear during high-speed operations.
Its C4 radial internal clearance allows for thermal expansion, ensuring reliable performance under varying conditions.
NU213-E-XL-M1-H257A-J20B-C4 Bearing’s dynamic load rating of 128 kN makes it suitable for heavy-duty applications.
The ceramic coating also offers high electrical resistance, even in damp conditions, enhancing durability.
Designed for efficiency, NU213-E-XL-M1-H257A-J20B-C4 Bearing operates smoothly at reference speeds up to 4900r/min.
Its robust construction ensures long service life, reducing maintenance needs and operational costs.
Industrial Uses of NU213-E-XL-M1-H257A-J20B-C4 Bearing
NU213-E-XL-M1-H257A-J20B-C4 Bearing is commonly used in electric motors and generators, where its current-insulating coating prevents electrical arcing. The brass cage ensures smooth operation even under high rotational speeds.
In wind turbine applications, NU213-E-XL-M1-H257A-J20B-C4 Bearing handles heavy radial loads while maintaining electrical insulation. Its C4 clearance allows for thermal expansion in variable temperature conditions.
For industrial pumps, NU213-E-XL-M1-H257A-J20B-C4 Bearing’s ceramic coating provides reliable performance in wet environments. The high dynamic load rating makes it suitable for continuous operation.
Where Is NU213-E-XL-M1-H257A-J20B-C4 Bearing Used?
NU213-E-XL-M1-H257A-J20B-C4 Bearing is ideal for conveyor systems in mining, where electrical insulation is crucial. Its robust design withstands harsh conditions and heavy loads.
In railway applications, NU213-E-XL-M1-H257A-J20B-C4 Bearing ensures reliable performance in traction motors. The ceramic coating prevents damage from stray currents.
Built for Heavy-Duty Use: NU213-E-XL-M1-H257A-J20B-C4 Bearing
NU213-E-XL-M1-H257A-J20B-C4 Bearing excels in steel mill equipment, handling extreme loads and high temperatures. The brass cage provides durability in demanding environments.
For paper manufacturing machinery, NU213-E-XL-M1-H257A-J20B-C4 Bearing offers long service life with minimal maintenance. Its electrical insulation protects against damage from moisture and chemicals.
Automotive vs Aerospace: Applications of NU213-E-XL-M1-H257A-J20B-C4 Bearing
In automotive electric power steering systems, NU213-E-XL-M1-H257A-J20B-C4 Bearing ensures smooth operation. The ceramic coating prevents electrical interference.
For aerospace applications, NU213-E-XL-M1-H257A-J20B-C4 Bearing’s lightweight design and insulation are key. It handles high speeds and loads in aircraft generators.
