The NU210-E-XL-M1-F1-J20AA-C4 is a current-insulated cylindrical roller bearing with a 50mm bore and 90mm outer diameter, designed to block electrical currents. Its outer ring features a ceramic coating, providing insulation up to 1000V.
With a dynamic load rating of 75kN and a static load rating of 69kN, it handles heavy radial loads smoothly. The brass cage ensures durability, while the C4 clearance allows for thermal expansion.
The bearing operates efficiently at speeds up to 6600r/min and works in temperatures typical for industrial settings. Its insulation makes it ideal for electric motors or generators where stray currents are a concern.
Weighing 0.532kg, it’s a robust yet manageable component. Compliant with RoHS and REACH standards, it’s a reliable choice for modern applications.
"*" indicates required fields
How Does NU210-E-XL-M1-F1-J20AA-C4 Bearing Resist Electrical Currents?
NU210-E-XL-M1-F1-J20AA-C4 Bearing features an outer ring ceramic coating, providing excellent insulation against electrical currents.
The coating offers a breakdown voltage of up to 1000V, making it suitable for applications with electrical interference.
Its brass cage ensures smooth operation and reduces friction, even at high speeds of 6600r/min.
The bearing’s C4 radial internal clearance allows for thermal expansion, maintaining performance under varying conditions.
With a basic dynamic load rating of 75 kN, NU210-E-XL-M1-F1-J20AA-C4 Bearing handles heavy loads reliably.
The ceramic coating also resists damp conditions, maintaining an electrical resistance of 10MΩ.
Designed for durability, NU210-E-XL-M1-F1-J20AA-C4 Bearing is ideal for electric motors and generators.
Its robust construction ensures long service life, reducing maintenance needs.
Industrial Uses of NU210-E-XL-M1-F1-J20AA-C4 Bearing
NU210-E-XL-M1-F1-J20AA-C4 Bearing is commonly used in electric motors and generators, where its current-insulating coating prevents electrical arcing. The brass cage ensures smooth operation even under high rotational speeds.
What Makes NU210-E-XL-M1-F1-J20AA-C4 Bearing a Preferred Choice?
In automation systems, NU210-E-XL-M1-F1-J20AA-C4 Bearing handles radial loads efficiently, making it ideal for robotic arms and conveyor belts. Its ceramic-coated outer ring adds durability in harsh industrial environments.
Perfect Fit for Automation: NU210-E-XL-M1-F1-J20AA-C4 Bearing
NU210-E-XL-M1-F1-J20AA-C4 Bearing works well in 3D printers, providing precise movement with minimal friction. The C4 clearance allows for thermal expansion in high-speed applications.
Automotive vs Aerospace: Applications of NU210-E-XL-M1-F1-J20AA-C4 Bearing
In automotive drivetrains, NU210-E-XL-M1-F1-J20AA-C4 Bearing supports components like alternators, while its insulation properties are valued in aerospace electrical systems. The 50MΩ dry resistance ensures reliable performance.
