The FAG NU1014-M1-F1-J20AA-C4 is a current-insulated cylindrical roller bearing with a 70mm bore and 110mm outer diameter, designed to handle electrical currents. Its outer ring features a ceramic coating for insulation, preventing damage from stray currents.
With a dynamic load rating of 77kN and a static load rating of 81kN, it supports heavy radial loads while spinning smoothly at up to 5500 RPM. The brass cage ensures durability and stable operation under stress.
The insulating coating provides a breakdown voltage of up to 1000V, making it ideal for electric motors or generators where electrical resistance is needed. It works well in both dry and damp conditions, with resistance levels of 50MΩ and 10MΩ respectively.
Weighing 0.71kg, this bearing is compact yet robust, suitable for industrial machinery requiring electrical insulation. Compliant with RoHS and REACH standards, it’s a reliable choice for modern applications.
"*" indicates required fields
How Does NU1014-M1-F1-J20AA-C4 Bearing Resist Electrical Current?
NU1014-M1-F1-J20AA-C4 Bearing features an outer ring ceramic coating, providing excellent insulation against electrical currents.
The coating offers a breakdown voltage of up to 1000V, ensuring reliable performance in electrically charged environments.
With a brass cage, NU1014-M1-F1-J20AA-C4 Bearing maintains stability and reduces friction during operation.
Its C4 radial internal clearance allows for thermal expansion, making it suitable for high-speed applications.
NU1014-M1-F1-J20AA-C4 Bearing’s dynamic load rating of 77 kN ensures durability under heavy loads.
The ceramic coating also resists damp conditions, maintaining an electrical resistance of 10MΩ.
Designed for precision, NU1014-M1-F1-J20AA-C4 Bearing operates smoothly at speeds up to 5500r/min.
Its compact size and lightweight design make it easy to integrate into various machinery.
Industrial Uses of NU1014-M1-F1-J20AA-C4 Bearing
NU1014-M1-F1-J20AA-C4 Bearing is commonly used in electric motors and generators, where its current-insulating properties prevent electrical damage. The ceramic coating on the outer ring ensures reliable performance in environments with stray currents.
What Makes NU1014-M1-F1-J20AA-C4 Bearing a Preferred Choice?
In wind turbines, NU1014-M1-F1-J20AA-C4 Bearing handles high radial loads while resisting electrical erosion. Its brass cage provides excellent durability, making it suitable for long-term use in renewable energy applications.
Perfect Fit for Automation: NU1014-M1-F1-J20AA-C4 Bearing
NU1014-M1-F1-J20AA-C4 Bearing works well in robotic arms and automated machinery, where precision and insulation are key. The C4 clearance allows for thermal expansion, ensuring smooth operation in varying temperatures.
Medical vs Industrial: Where NU1014-M1-F1-J20AA-C4 Bearing Excels
While NU1014-M1-F1-J20AA-C4 Bearing isn’t typically used in medical devices, it shines in industrial settings like conveyor systems. Its high dynamic load rating makes it ideal for heavy-duty applications.
Key Fields for NU1014-M1-F1-J20AA-C4 Bearing
NU1014-M1-F1-J20AA-C4 Bearing is a go-to for railway traction motors, thanks to its ability to withstand electrical currents. The 5500r/min reference speed ensures it meets the demands of high-speed transport systems.
