The FAG NU1013-XL-M1-F1-J20AA-C4 is a current-insulated cylindrical roller bearing, measuring 65mm in bore diameter and 100mm outside diameter, with a width of 18mm. Its outer ring features a ceramic coating for electrical insulation, preventing current damage.
This bearing handles dynamic loads up to 53 kN and static loads up to 58 kN, with a reference speed of 5900 rpm. The brass cage ensures smooth operation and durability under high-speed conditions.
The insulating coating provides a breakdown voltage of up to 1000V, making it ideal for electric motors or generators where electrical currents are present. Its C4 radial clearance allows for thermal expansion in demanding environments.
Weighing 0.512 kg, it’s a compact yet robust solution for industrial applications. Compliant with RoHS and REACH standards, it’s both reliable and environmentally friendly.
"*" indicates required fields
How Is NU1013-XL-M1-F1-J20AA-C4 Bearing Engineered for Reliability?
NU1013-XL-M1-F1-J20AA-C4 Bearing features an outer ring ceramic coating, providing excellent electrical insulation.
This design prevents current passage, reducing the risk of damage in electrically active environments.
The brass cage ensures stable operation, even at high speeds up to 5,900 rpm.
With a basic dynamic load rating of 53 kN, it handles heavy radial loads efficiently.
NU1013-XL-M1-F1-J20AA-C4 Bearing’s C4 radial internal clearance allows for thermal expansion in demanding conditions.
Its robust construction ensures long service life and minimal maintenance requirements.
Industrial Uses of NU1013-XL-M1-F1-J20AA-C4 Bearing
NU1013-XL-M1-F1-J20AA-C4 Bearing is commonly used in electric motors and generators, where its current-insulating coating prevents electrical arcing. The brass cage ensures smooth operation even under high rotational speeds.
In automation systems, NU1013-XL-M1-F1-J20AA-C4 Bearing supports precision movements in robotic arms and conveyor belts. Its C4 clearance allows for thermal expansion in demanding environments.
For wind turbine applications, NU1013-XL-M1-F1-J20AA-C4 Bearing’s ceramic-coated outer ring provides reliable insulation against stray currents. The high dynamic load rating makes it suitable for continuous operation.
Where Is NU1013-XL-M1-F1-J20AA-C4 Bearing Used?
NU1013-XL-M1-F1-J20AA-C4 Bearing finds its place in industrial pumps, handling both radial loads and electrical insulation needs. The M1 suffix indicates optimized internal design for reduced noise.
In railway systems, NU1013-XL-M1-F1-J20AA-C4 Bearing helps in traction motors, where its damp electrical resistance maintains performance. The 18mm width offers a compact solution for space-constrained designs.
Built for Heavy-Duty Use: NU1013-XL-M1-F1-J20AA-C4 Bearing
NU1013-XL-M1-F1-J20AA-C4 Bearing excels in steel mill equipment, withstanding high temperatures and heavy loads. The ceramic coating ensures long-term insulation stability.
For food processing machinery, NU1013-XL-M1-F1-J20AA-C4 Bearing’s brass cage resists corrosion from washdowns. Its 100mm outer diameter provides stable support for rotating shafts.
Automotive vs Aerospace: Applications of NU1013-XL-M1-F1-J20AA-C4 Bearing
In automotive alternators, NU1013-XL-M1-F1-J20AA-C4 Bearing prevents current leakage while maintaining efficiency. The C4 clearance accommodates thermal changes during operation.
For aerospace actuators, NU1013-XL-M1-F1-J20AA-C4 Bearing’s lightweight design and insulation properties are crucial. The 5900r/min reference speed meets high-performance requirements.
