The FAG NU1007-XL-M1-F1-J20AA-C4 is a current-insulated cylindrical roller bearing with a 35mm bore and 62mm outer diameter, featuring a ceramic-coated outer ring. It handles dynamic loads up to 29 kN and spins smoothly at speeds up to 9700 RPM.
Its brass cage ensures durability, while the C4 radial clearance allows for thermal expansion in demanding conditions. The insulating coating prevents electrical arcing, with a breakdown voltage of up to 1000V.
This bearing is ideal for electric motors or generators where current insulation is needed. It works well in damp conditions, maintaining a resistance of 10MΩ.
Weighing just 0.18kg, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe use.
"*" indicates required fields
Why Choose NU1007-XL-M1-F1-J20AA-C4 Bearing for Precision Tasks?
NU1007-XL-M1-F1-J20AA-C4 Bearing features an outer ring ceramic coating, providing excellent electrical insulation.
This design prevents current passage, making it ideal for applications where electrical currents are a concern.
The brass cage ensures smooth operation and reduces friction, enhancing the bearing’s performance.
With a basic dynamic load rating of 29 kN, it handles heavy loads efficiently.
NU1007-XL-M1-F1-J20AA-C4 Bearing operates at high speeds, up to 9700r/min, without compromising reliability.
Its C4 radial internal clearance allows for thermal expansion in demanding environments.
The coating offers high electrical resistance, with 50MΩ when dry and 10MΩ in damp conditions.
This ensures consistent performance even in varying environmental conditions.
NU1007-XL-M1-F1-J20AA-C4 Bearing is ROHS and REACH compliant, meeting strict environmental standards.
Its compact size and lightweight design make it easy to integrate into various applications.
Industrial Uses of NU1007-XL-M1-F1-J20AA-C4 Bearing
NU1007-XL-M1-F1-J20AA-C4 Bearing is commonly used in electric motors and generators, where its current-insulating coating prevents electrical arcing. The brass cage ensures smooth operation even under high rotational speeds.
In automation systems, NU1007-XL-M1-F1-J20AA-C4 Bearing supports precise movements in robotic arms and CNC machines. Its C4 clearance allows for thermal expansion in demanding industrial environments.
For wind turbine applications, NU1007-XL-M1-F1-J20AA-C4 Bearing’s ceramic coating provides reliable insulation against stray currents. The high dynamic load rating makes it suitable for continuous operation in renewable energy systems.
What Makes NU1007-XL-M1-F1-J20AA-C4 Bearing a Preferred Choice?
NU1007-XL-M1-F1-J20AA-C4 Bearing is often chosen for railway traction motors due to its ability to handle both radial loads and electrical isolation. The dry electrical resistance of 50MΩ ensures consistent performance.
In industrial pumps, NU1007-XL-M1-F1-J20AA-C4 Bearing’s robust design withstands constant vibration and high-speed rotation. Its 14mm width makes it compact enough for space-constrained installations.
Built for Heavy-Duty Use: NU1007-XL-M1-F1-J20AA-C4 Bearing
NU1007-XL-M1-F1-J20AA-C4 Bearing excels in steel mill equipment where high temperatures and heavy loads are common. The ceramic coating maintains insulation properties even in harsh conditions.
For food processing machinery, NU1007-XL-M1-F1-J20AA-C4 Bearing’s stainless components resist corrosion from washdowns. The 62mm outer diameter provides a stable fit in conveyor systems.
Automotive vs Aerospace: Applications of NU1007-XL-M1-F1-J20AA-C4 Bearing
In automotive alternators, NU1007-XL-M1-F1-J20AA-C4 Bearing prevents electrical damage from voltage spikes. Its 35mm bore fits standard shaft sizes in most vehicle models.
For aircraft auxiliary systems, NU1007-XL-M1-F1-J20AA-C4 Bearing’s lightweight design (0.18kg) reduces overall component weight. The 9700r/min speed rating meets aviation performance standards.
